6
English
Connector
•
1 x COM Port Header
•
1 x TPM Header
•
1 x Power LED and Speaker Header
•
1 x AURA RGB LED Header
•
1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x CPU Optional/Water Pump Fan Connector (4-pin)
* e CPU Optional/Water Pump Fan supports the water cooler
fan of maximum 1.5A (18W) fan power.
•
2 x Chassis Fan Connectors (4-pin)
•
1 x Chassis Optional/Water Pump Fan Connector (4-pin)
* e Chassis Optional/Water Pump Fan supports the water
cooler fan of maximum 1.5A (18W) fan power.
•
1 x 24 pin ATX Power Connector (Hi-Density Power Con-
nector)
•
1 x 8 pin 12V Power Connector (Hi-Density Power Connec-
tor)
•
1 x 6 pin 12V Power Connector (Hi-Density Power Connec-
tor)
•
1 x Front Panel Audio Connector (15μ Gold Audio Connec-
tor)*
•
1 x Right Angle Front Panel Audio Connector*
* Connect the audio device to either one of the audio connec-
tors.
•
2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Intel® Z270)
(Supports ESD Protection (ASRock Full Spike Protection))
•
2 x USB 3.0 Headers (Support 4 USB 3.0 ports) (ASMedia
ASM1074 hub) (Supports ESD Protection (ASRock Full Spike
Protection))
•
1 x Vertical Type A USB 3.0 (Intel® Z270)
•
1 x Dr. Debug with LED
•
1 x Power Switch with LED
•
1 x Reset Switch with LED
•
1 x XMP Switch
BIOS
Feature
•
2 x AMI UEFI Legal BIOS with multilingual GUI support (1
x Main BIOS and 1 x Backup BIOS)
•
Supports Secure Backup UEFI Technology
•
ACPI 6.0 Compliant wake up events
•
SMBIOS 2.7 Support
