English
5
X399 Taichi
•
1 x 24 pin ATX Power Connector (Hi-Density Power
Connector) (for Motherboard)
•
1 x 8 pin 12V Power Connector (Hi-Density Power
Connector) (for Motherboard)
•
1 x 4 pin 12V Power Connector (Hi-Density Power
Connector) (for Motherboard)
•
1 x 6 pin 12V Power Connector (Hi-Density Power
Connector) (for PCIe graphics card)
•
1 x Front Panel Audio Connector (15μ Gold Audio
Connector)*
•
1 x Right Angle Front Panel Audio Connector*
* Connect the audio device to either one of the audio
connectors.
•
2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports
ESD Protection)
•
2 x USB 3.0 Headers (Support 4 USB 3.0 ports) (Supports
ESD Protection)
•
1 x Clear CMOS Switch
•
1 x Dr. Debug with LED
•
1 x Power Switch with LED
•
1 x Reset Switch with LED
•
1 x CPU Xtreme OC Switch
BIOS
Feature
•
AMI UEFI Legal BIOS with GUI support
•
Supports “Plug and Play”
•
ACPI 5.1 compliance wake up events
•
Supports jumperfree
•
SMBIOS 2.3 support
•
CPU, VCORE_NB, DRAM, VPPM, PCH 1.05V, +1.8V,
VDDP, PROM 2.5V, Voltage Multi-adjustment
Hardware
Monitor
•
Temperature Sensing: CPU, CPU Optional/Water Pump,
Chassis, Chassis Optional/Water Pump Fans
•
Fan Tachometer: CPU, CPU Optional/Water Pump, Chassis,
Chassis Optional/Water Pump Fans
•
Quiet Fan (Auto adjust chassis fan speed by CPU
temperature): CPU, CPU Optional/Water Pump, Chassis,
Chassis Optional/Water Pump Fans
