USB
Intel
®
Z370 Chipset
- 6 x USB 3.1 Gen 1 ports ( 4 ports at back panel [blue], 2 ports at
mid-board [grey])
- 6 x USB 2.0 ports ( 4 ports at back panel [black], 2 ports at mid-
board [black])
ASMedia
®
USB 3.1 controller
- 1 x USB 3.1 Gen 2 front panel connector
- 2 x USB 3.1 Gen 2 ports (1 Type-A [red] and 1 Type-C [black] at
back panel)
ROG Exclusive Features
Extreme Engine Digi+
- MicroFine Alloy Choke
- NexFET MOSFETs
- 10K Black Metallic Capacitors
ROG Armor
Pre-mounted I/O Shield
ROG Aura
- Aura effects (LOGO)
- 2 x Aura RGB headers
- 2 x Aura addressable RGB headers
Start Button
Reset Button
Safe Boot Button
ReTry Button
BIOS Flashback Button
Clear CMOS Button
MemOK! Button
LN2 Mode
ROG RAMDisk
ROG CloneDrive
ROG RAMCache II
KeyBot II
- X.M.P.
- Clr CMOS
- Power On
UEFI BIOS features:
- Extreme Tweaker
- Tweakers’ Paradise
- ROG SSD Secure Erase
- O.C. Prole
- Graphics Card Information Preview
ROG MAXIMUS X CODE specifications summary
