Asus WS C422 PRO/SE [15/130] Installation tools and components
![Asus WS C422 PRO/SE [15/130] Installation tools and components](/views2/1307901/page15/bgf.png)
xv
Installation tools and components
The tools and components in the table above are not included in the motherboard package.
PC chassis
Power supply unit
Intel
®
LGA2066 compatible CPU Fan
Intel
®
LGA2066 CPU
DIMM
SATA hard disk drive
Graphics card
Phillips (cross) screwdriver
SATA optical disc drive (optional)
1 bag of screws
