1-2

Chapter 1: Product introduction

ATX power connectors (24-pin EATXPWR, 4-pin ATX12V)

CorrectlyorienttheATXpowersupplyplugsintotheseconnectorsandpushdown

rmlyuntiltheconnectorscompletelyt.

•

Forafullyconguredsystem,werecommendthatyouuseapowersupplyunit

(PSU)thatcomplieswithATX12VSpecication2.0(orlaterversion)andprovides

aminimumpowerof300W.

•

Ifyouareuncertainabouttheminimumpowersupplyrequirementforyoursystem,

refertotheRecommendedPowerSupplyWattageCalculatorathttp://support.

asus.com/PowerSupplyCalculator/PSCalculator.aspx?SLanguage=en-usfor

details.

CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN1/2)

Connectthefancablestothefanconnectorsonthemotherboard,ensuringthatthe

blackwireofeachcablematchesthegroundpinoftheconnector.

Donotforgettoconnectthefancablestothefanconnectors.Insufcientairowinside

thesystemmaydamagethemotherboardcomponents.Thesearenotjumpers!Donot

placejumpercapsonthefanconnectors!TheCPU_FANconnectorsupportsaCPUfan

ofmaximum2A(24W)fanpower.

Onlythe4-pinCPUfansupportstheASUSFanXpertfeature.

AMD AM4 CPU socket

ThemotherboardcomeswithanAM4socketdesignedforAMDRyzen™/7th

GenerationA-series/Athlon™processorsupto8-core.

Formoredetails,refertoCentral Processing Unit (CPU).

DDR4 DIMM slots

Install2GB,4GB,8GB,and16GB,unbufferedandnon-ECCDDR4DIMMsinto

theseDIMMsockets.

Formoredetails,refertoSystem memory.

Serial port connector (10-1 pin COM2)

Thisconnectorisforaserial(COM)port.Connecttheserialportmodulecableto

thisconnector,theninstallthemoduletoaslotopeningatthebackofthesystem

chassis.

LPT connector (26-1 pin LPT)

TheLPT(LinePrintingTerminal)connectorsupportsdevicessuchasaprinter.

LPTstandardizesasIEEE1284,whichistheparallelportinterfaceonIBMPC-

compatiblecomputers.
