PCI slot

ThePCIslotsupportscardssuchasaLANcard,SCSIcard,USBcard,andother

cardsthatcomplywithPCIspecications.

PCI Express 2.0 x1 slots

ThismotherboardsupportsPCIExpress2.0x1networkcards,SCSIcards,and

othercardsthatcomplywiththePCIExpressspecications

PCI Express 3.0/2.0 x16 slot

ThismotherboardsupportsPCIExpressx16networkcards,SCSIcards,andother

cardsthatcomplywiththePCIExpressspecications.

DuetoCPUlimitation,PCIExpress3.0/2.0x16slotsupportedvariesbyprocessor.

1. PS/2 Mouse port (green).ThisportisforaPS/2mouse.

2. Video Graphics Adapter (VGA) port.This15-pinportisforaVGAmonitororother

VGA-compatibledevices.

3. Serial port.This9-pinCOMportisforpointingdevicesorotherserialdevices.

4. LAN (RJ-45) port.ThisportallowsGigabitconnectiontoaLocalAreaNetwork(LAN)

throughanetworkhub.

Rear panel connectors

2 3

5 64

789

1011

LAN port

Speed

LED

Activity Link

LED

LAN port LED indications

Activity/Link LED Speed LED

Status Description Status Description

OFF Nolink OFF 10Mbpsconnection

ORANGE Linked ORANGE 100Mbpsconnection

BLINKING Dataactivity GREEN 1Gbpsconnection

5. Line In port (light blue).Thisportconnectstothetape,CD,DVDplayer,orother

audiosources.
