System memory

Overview

ThismotherboardcomeswithtwoDoubleDataRate4(DDR4)DualInlineMemoryModule

(DIMM)sockets.ADDR4moduleisnotcheddifferentlyfromaDDR,DDR2,orDDR3module.

DONOTinstallaDDR,DDR2,orDDR3memorymoduletotheDDR4slot.

Channel Sockets

ChannelA DIMM_A1

ChannelB DIMM_B1

• YoumayinstallvaryingmemorysizesinChannelAandChannelB.Thesystem

mapsthetotalsizeofthelower-sizedchannelforthedual-channelconguration.Any

excessmemoryfromthehigher-sizedchannelisthenmappedforsingle-channel

operation.

• AlwaysinstalltheDIMMSwiththesameCASLatency.Foranoptimumcompatibility,

werecommendthatyouinstallmemorymodulesofthesameversionordatacode

(D/C)fromthesamevendor.Checkwiththevendortogetthecorrectmemory

modules.

• ThismotherboarddoesnotsupportDIMMsmadeupof512Mb(64MB)chipsorless.

VisittheASUSwebsiteatwww.asus.comforthelatestQVL.

DIMM_A1

DIMM_B1

Installing a DIMM

To remove a DIMM

Recommended memory congurations
