![Asus PRIME A320M-C R2.0 [7/25] Prime a320m c r2 specifications summary](/views2/1307910/page7/bg7.png)
vii
PRIME A320M-C R2.0 specications summary
(continued on the next page)
Storage
AMD Ryzen™ Processors
- 1 x M.2 socket 3 with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA
modes) storage devices support
AMD 7th Generation A-series/Athlon™ Processors
- 1 x M.2 socket 3 with M Key, Type 2242/2260/2280 (SATA mode) storage
devices support
AMD A320 Chipset
- 4 x Serial ATA 6.0 Gb/s connectors with RAID 0, RAID 1, and RAID 10 support
Audio
Realtek
®
ALC 887-VD2 8-Channel High Denition Audio CODEC
* Use a chassis with HD audio module in the front panel to support an 8-channel audio
output.
USB
6 x USB 3.0 / 2.0 ports (4 ports at the rear panel; 2 ports at mid-board)
6 x USB 2.0 / 1.1 ports (2 ports at the rear panel; 4 ports at mid-board)
ASUS unique
features
Dependable Stability
ASUS 5X PROTECTION II
- ASUS LANGuard - Surge-protected networking
- ASUS Overvoltage Protection - World-class circuit-protecting power design
- ASUS DRAM Overcurrent Protection - Enhanced DRAM overcurrent protection
- ASUS Stainless Steel Back I/O - 3X more durable
- ESD Guards - Electrostatic discharge protection
Superb performance
UEFI BIOS
- Most advanced options with fast response time
Easy PC DIY
Safe motherboard mounting
- Component-free areas to minimize damage risk
Q-Design
- ASUS Q-DIMM
- ASUS Q-Slot
UEFI BIOS EZ Mode - featuring friendly graphics user interface
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
Optimized Cooling
- Stylish Fanless Design: Chipset Heat-sink solution
- ASUS Fan Xpert
Rear panel
I/O ports
1 x PS/2 keyboard (purple)
1 x PS/2 mouse port (green)
1 x HDMI port
1 x DVI-D port
1 x D-Sub port
1 x COM port
1 x LAN (RJ-45) port
4 x USB 3.0/2.0 ports
2 x USB 2.0/1.1 ports
3 x Audio jacks support 8-channel audio output
