1-6

Chapter 1: Product introduction

9. HDMI port. This port is for a High-Denition Multimedia Interface (HDMI) connector,

and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected

content.

10. DVI-D port. This port is for any DVI-D compatible device.

DVI-D can not be converted to output from RGB Signal to CRT and is not compatible with

DVI-I.

11. PS/2 keyboard (purple) port. This port is for a PS/2 keyboard.

Audio 2.1, 4.1, 5.1 or 7.1-channel conguration

Port

Headset

2.1-channel

4.1-channel 5.1-channel 7.1-channel

Light Blue (Rear panel) Line In Rear Speaker Out Rear Speaker Out Rear Speaker Out

Lime (Rear panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out

Pink (Rear panel) Mic In Mic In Bass/Center Bass/Center

Lime (Front panel) - - - Side Speaker Out

6. Line In port (light blue). This port connects to the tape, CD, DVD player, or other

audio sources.

7. Line Out port (lime). This port connects to a headphone or a speaker. In the 4.1,

5.1and 7.1-channel congurations, the function of this port becomes Front Speaker

Out.

8. Microphone port (pink). This port connects to a microphone.

Refer to the audio conguration table for the function of the audio ports in 2.1, 4.1, 5.1, or

7.1-channel conguration.
