1-4

Chapter 1: Product introduction

Front panel audio connector (10-1 pin AAFP)

Thisconnectorisforachassis-mountedfrontpanelaudioI/Omodulethatsupports

eitherHDAudioorlegacyAC`97audiostandard.Connectoneendofthefront

panelaudioI/Omodulecabletothisconnector.

• Werecommendthatyouconnectahigh-denitionfrontpanelaudiomoduletothis

connectortoavailofthemotherboard’shigh-denitionaudiocapability.

• Ifyouwanttoconnectahigh-denitionfrontpanelaudiomoduletothisconnector,

settheFrontPanelTypeitemintheBIOSsetupto[HDAudio].Ifyouwantto

connectanAC’97frontpanelaudiomoduletothisconnector,settheitemto

[AC97].Bydefault,thisconnectorissetto[HDAudio].

PCI Express 2.0 x1 slots

ThismotherboardhastwoPCIExpress2.0x1slotsthatsupportPCIExpressx1

networkcards,SCSIcards,andothercardsthatcomplywiththePCIExpress

specications.

PCI Express 3.0/2.0 x16 slot

ThismotherboardsupportsonePCIExpress3.0/2.0x16graphiccardthatcomplies

withthePCIExpressspecications.

IRQ assignments for this motherboard

WhenusingPCIcardsonsharedslots,ensurethatthedriverssupport“ShareIRQ”orthat

thecardsdonotneedIRQassignments.Otherwise,conictswillarisebetweenthetwoPCI

groups,makingthesystemunstableandthecardinoperable.

A B C D E F G H

HDAudiocontroller shared – – – – – – –

XHCIcontroller shared – – – – – – –

SATAcontroller shared – – – – – – –

RealtekLAN

controller

– – – shared – – – –

PCIex16 shared – – – – – – –

PCIex1_1 shared – – – – – – –

PCIex1_2 – shared – – – – – –
