![Asus H110M-F [7/26] H110m f specifications summary](/views2/1307922/page7/bg7.png)
vii
H110M-F specications summary
(continued on the next page)
Audio
Realtek
®
ALC887 8-channel* High Denition Audio CODEC
- Audio Shielding: Ensures precision analog/digital separation and greatly
reduced multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right channels to
guard the quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural and immersive
sound with exceptional clarity and delity
- Supports Jack-Detection and Front Panel Jack-Retasking
* Use a chassis with HD audio module in the front panel to support an 8-channel audio
output.
USB
Intel
®
H110 Chipset
- 4 x USB 3.0/2.0 ports (2 ports at mid-board; 2 ports at back panel, blue,
Type A)
- 6 x USB 2.0/1.1 ports (2 ports at mid-board; 4 ports at back panel)
ASUS special
features
ASUS 5X PROTECTION II
- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-
electricity discharges
- ASUS Overvoltage Protection: World-class circuit-protecting power design
- ASUS DIGI+ VRM: 3+1 Phase digital power design
- ASUS DRAM Overcurrent Protection: Enhanced DRAM overcurrent
protection
- ASUS Stainless Steel Back I/O: 3X corrosion-resistance for greater
durability
Superb Performance
UEFI BIOS EZ Mode
- Most advanced options with fast response time
ASUS EPU
- EPU
Gaming Scenario
Audio Features
- Audio that roars on the battleeld
ASUS Exclusive Features
- ASUS AI Charger
- ASUS AI Suite 3
EZ DIY
UEFI BIOS EZ Mode
- Featuring friendly graphics user interface
- ASUS EZ Flash 3
Q-Design
- ASUS Q-DIMM
- ASUS Q-Slot
ASUS Quiet
Thermal
Solution
Quiet Thermal Design
- ASUS Fan Xpert
- Stylish Fanless Design: PCH Heat-sink solution
