vi
H110M-F specications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS H110M-F motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
CPU
LGA1151 socket for Intel
®
7th/6th Generation Core™ i7 / i5 / i3, Pentium
®
, and
Celeron
®
processors
Supports Intel
®
14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H110 Chipset
Memory
2 x DIMMs, maximum 32GB, DDR4 2400*/2133**MHz, non-ECC, un-buffered
memory***
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Due to Intel
®
chipset limitation, DDR4 2400MHz memory frequency is only supported
by 7th Generation Intel
®
processors. Higher memory modules will run at the maximum
transfer rate of DDR4 2400MHz.
** Due to Intel
®
chipset limitation, DDR4 2133MHz and higher memory modules on 6th
Generation Intel
®
processors will run at the maximum transfer rate of DDR4 2133MHz.
*** Hyper DIMM support is subject to the physical characteristics of individual CPUs.
Refer to the Memory QVL(Qualied Vendors List) for details.
**** Refer to www.asus.com for the Memory QVL(Qualied Vendors List).
Expansion
slots
1 x PCI Express 3.0/2.0 x16 slot (at x16 mode)
2 x PCI Express 2.0 x1 slots
Graphics
Integrated graphics processor - Intel
®
HD Graphics support
- Supports D-Sub with maximum resolution of 1920 x 1200 @ 60Hz
Supports Intel
®
InTru™ 3D, Quick Sync Video, Intel
®
Clear Video HD Technology,
and Intel
®
Insider™
Maximum shared memory of 1024 MB
Storage
Intel
®
H110 Chipset:
- 4 x SATA 6.0 Gb/s ports (gray)
LAN Realtek
®
8111H Gigabit LAN controller support LANGuard
