INSTALLATION INSTRUCTIONS

INSTALLATION OF MODELS WITH DECORATIVE DUCTS  EXTRACTOR HOOD

Before installing decorative  ues it is necessary to remove the small cupola and loosen the 4 screws B that lock the

fastening pins G as shown in Fig.7.

Make sure the electrical power supply is within the measurements of the decorative connector.

Connect  ange F to the air exhaust hole using  exible hose L (Fig.7).

Adjust the width of the support bracket of the top connector (Fig. 8). Then  x it to the ceiling so that it is on the same

axis as the hood using screws A and observing the distance from the ceiling shown in (Fig. 8). Slide the top connector

inside the lower duct and place this on the body (Fig. 9).

Pull out the top duct as far as the bracket and secure it using screws B (Fig. 8).

To transform the hood from a ducting version into a  ltering version, ask your dealer for the charcoal  lters and follow

the installation instructions.

FILTERING VERSION

Unhook the small cupola M and remove the grille E (Fig. 5).

Pass the power supply cable through the slots of the small cupola M as shown in Fig. 6.

Take the fairlead H and position it between the power supply cable and the slot.

Fasten the small cupola M and the grille E making sure that is it perfectly hooked on to the fastening pins G. (Fig. 6).

The  lters must be applied to the suction unit positioned inside the hood. They must be centred by turning them 90

degrees until the stop catch is tripped (Fig.10B).

In order to transform the hood from EXTRACTOR HOOD into FILTER HOOD the active carbon  lters must be

ordered at your distributor as accessory.

We have 3 di erent types of Kit, one with non-regenerable active carbon  lters (Fig.10B) and the other one with

regenerable active charcoal  lters (washable) (Fig.10C - Fig.10D).

Depending on the model one owns, the CIRCULAR active carbon  lters must be applied to the suction unit located

inside the hood, centring them and rotating them by 90 degrees until they snap into place (Fig.10B), to replace them

perform the operation in reverse order.

For WASHABLE regenerable activated carbon  lters (Fig.10C), follow the assembly instructions contained in the KIT.

For the WASHABLE CIRCULAR regenerable active carbon  lters (Fig.10D), remove the pad and follow the instructions

in the USE AND MAINTENANCE paragraph, «regenerable active carbon  lters».

USE AND MAINTENANCE

We recommend that the cooker hood is switched on before any food is cooked. We also recommend that the

appliance is left running for 15 minutes after the food is cooked, in order to thoroughly eliminate all contaminated air.

The e ective performance of the cooker hood depends on constant maintenance; the anti-grease  lter and the active

carbon  lter both require special attention.

The anti-grease  lter is responsible retaining the grease particles suspended in the air, therefore it is subject to

clogging with variable frequency according to the use of the appliance.

To prevent the danger of possible  res, at least every 2 months one must wash the anti-grease  lters by hand using

non-abrasive neutral liquid detergents or in the dishwasher at low temperatures and on short cycles.

After a few washes, colour alterations may occur. This does not give the right to claim their replacement.
