Chapter 1
Introduction
1-1 Overview
The SuperServer 6028R-TR/TRT is a high-end server comprised of two main
subsystems: the SC825TQ-R740LPB 2U chassis and the X10DRi-/X10DRi-T dual
processor serverboard. Please refer to our web site for information on operating
systems that have been certied for use with the system (www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have
been included with the 6028R-TR/TRT, as listed below:
• Two passive CPU heatsinks (SNK-P0048PS)
• Three 8-cm system fans (FAN-0126L4)
• One air shroud (MCP-310-29001-0N)
• SATA Accessories
One SATA backplane (BPN-SAS-825TQ-O-P)
Eight drive carriers (MCP-220-00075-0B)
• One rackmount kit (MCP-290-00053-0N)
Note: For your system to work properly, please follow the links below to download
all necessary drivers/utilities and the user's manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety info: http://www.supermicro.com/about/policies/safety_informa-
tion.cfm
• If you have any questions, please contact our support team at support@su-
permicro.com
