1-2 1-3
Chapter 1: Introduction
SUPERSERVER 6028R-TR/TRT User's Manual
1-2 Serverboard Features
The SuperServer 6028R-TR/TRT is built around the X10DRi-/X10DRi-T, a dual pro-
cessor serverboard based on the Intel® PCH C612 chipset and designed to provide
maximum performance. Below are the main features of the X10DRi-/X10DRi-T. (See
Figure 1-1 for a block diagram of the chipset).
Processors
The X10DRi-/X10DRi-T supports single or dual Intel E5-2600 (v3/v4) Series (Socket
R3) processors in LGA 2011 sockets. Please refer to our website for a complete
listing of supported processors (www.supermicro.com). Note that with only a single
processor installed (in the CPU1 socket), PCI-E slots 4~6 will not function.
Memory
The X10DRi-/X10DRi-T has sixteen DIMM slots that can support up to 1 TB of
ECC LRDIMM or ECC RDIMM DDR4-2400/2133/1866/1600 memory. Please refer
to Chapter 5 for details on installing memory.
SATA
A SATA controller is integrated into the chipset to provide a ten-port SATA 3.0
subsystem, which is RAID 0, 1, 10 and 5 capable. Six ports are supported by the
Intel PCH: I-SATA0-5 (I-SATA 4 and 5 are colored yellow to indicate that they have
embedded power to support SATA DOMs) and four are supported by the Intel SCU
(S-SATA0-3).
PCI Expansion Slots
The X10DRi/X10DRi-T has three PCI-E 3.0 x16 and three PCI-E 3.0 x8 expansion
slots. Note that the PCI slots are controlled by the CPU so some slots may not be
available when two CPUs are not installed on the board at the same time. See the
serverboard layout in Chapter 5 for details.
I/O Ports
The I/O ports include one COM port, a VGA (monitor) port, four USB ports, two
Ethernet LAN ports (10 Gb ports on the X10DRi-T and 1 Gb ports on the X10DRi)
and a dedicated IPMI LAN port.
Graphics Controller
The X10DRi-/X10DRi-T features an integrated Aspeed 2400 controller.
1-3 Server Chassis Features
The SC825TQ-R740LPB is an ATX form factor chassis designed to be used in a
2U rackmount conguration. The following is a general outline of the main features
of the SC825TQ-R740LPB server chassis.
System Power
The SC825TQ-R740LPB features a redundant 740W power supply composed of
two separate power modules. This power redundancy feature allows you to replace
a failed power supply module without shutting down the system.
Hard Drive Subsystem
The SC825TQ-R740LPB chassis was designed to support eight hot-swap SATA
hard drives.
Front Control Panel
The control panel on the SC825TQ-R740LPB provides you with system monitoring
and control. LEDs indicate system power, HDD activity, network activity, system
information and power supply failure. A main power button and a system reset but-
ton are also included. As an option, two USB ports may be incorporated into the
control panel to provide front side USB access.
Cooling Fans
The SC825TQ-R740LPB chassis has an innovative cooling design that includes
three 8-cm hot-plug system cooling fans located in the middle section of the chas-
sis. The power supply module also includes a cooling fan.
