Liebherr IKB 2360 [4/18] Unit door
![Liebherr IK 2760 [4/18] Unit door](/views2/1317311/page4/bg4.png)
Fig. 2
D
(mm
)
E
(mm
)
F (mm) G
(mm
)
H
(mm
)
J
(mm
)
IG 10..,
IGN 10..
714
—
730
560
—
570
min.
550, we
recom-
mend
560
min.
500
min.
40
max.
19
IK 16..,
IKP 16.. ,
IG 16.. ,
IGN 16.., IB
16..
874
—
890
IK 19.., IKB
19..
1024
—
1040
IK 23..,
IKP 23..,
IKB 23..,
IKBP 23..
1220
—
1236
IK 27..,
IKB 27..,
IKBP 27..,
IGN 27..
1397
—
1413
IKBP 29.. 1574
—
1590
IK 35.., IKF
35..,
IKB 35..,
IKBP 35..,
IGN 35..,
SIGN 35..
1772
—
1788
The specified energy consumption applies to a unit depth of
560 mm. The appliance will work properly at a unit depth of 550
mm, but at a slightly higher energy consumption.
u
In the case of Side-by-Side installa-
tion, two appliances next to one
another, build the appliances into
separate kitchen units.
u
Check the wall thickness of the adjoining cabinets: it must
be min. 16 mm thick.
u
Only install the appliance in robust, stable kitchen units.
Secure the units against tipping.
u
Align the kitchen unit using a spirit level and marking square
and if necessary compensate with shims.
u
Ensure that the floor and walls of the unit are at right angles
to one another.
6 Unit door
-
One door is required for the kitchen unit.
-
The door must be minimum 16 mm and maximum 19 mm
thick.
-
There must be a gap of minimum 3 mm width between the
door and the unit door located above it (if one exists).
-
The width of the unit door depends on the style of the
kitchen and the gap size between the door panels of the
cabinet. Generally, there should remain a vertical gap of
3 mm between the unit doors.
-
If other cabinets are present, the top edge of the unit door
should be on a level with the doors of the adjoining units.
-
The unit door must be planar and mounted stress-free.
NOTICE
Risk of damage from over-heavy unit door!
If the unit door is too heavy, damage to the hinges and resulting
impairment of function cannot be excluded.
u
Before mounting the unit door, make sure that the door does
not exceed the approved unit door weight.
Appliance model Maximum cabinet
door weight (kg)
IK 19.., IKB 19.. 13
IG 10.., IGN 10.. 14
IK 16.., IKP 16.., IG 16.., IGN 16..,
IB 16..
16
IKB 23.., IKBP 23.., IK 23..,
IKP 23..
19
IK 27.., IKB 27.., IKBP 27.., IGN
27..
21
IKBP 29.. 22
IK 35.., IKF 35.., IKB 35..,
IKBP 35.., IGN 35.., SIGN 35..
26
Unit door
4 * Depending on model and options
