Liebherr CN 4023 [10/16] Using the sectioned shelf

Fig. 10

Lift the shelf slightly and pull forward a little.

Adjust the height of the shelf. To do so, push the cut-outs

along the supports.

In order to remove the shelf fully, place it at a slant and pull

out towards the front.

Insert shelf with the raised edge pointing upwards at the

back.

The food does not freeze onto the rear wall.

Dismantling shelves

The shelves can be disman-

tled for cleaning.

5.3.5 Using the sectioned shelf*

Fig. 11

The glass shelf with stop face (2) has to be at the back.

5.3.6 Door racks

Moving the storage rack

Remove storage rack according to

illustration.

The boxes can be removed

and placed on the table as a

single unit.*

Three small boxes are available through the customer service

as optional equipment instead of one wide and one small box.*

Either one or both the boxes can be used. If particularly tall

bottles are to be stored, hang only a single box above the bottle

rack.*

Re-positioning the boxes:

Lift them for removal and

re-position them as

required.*

Dismantling door racks

Fig. 12

The door racks can be dismantled for cleaning.

5.3.7 Removing the bottle holder*

Always take hold of the bottle holder

on the plastic part.

5.4 Freezer compartment

You can store frozen food, make ice cubes and freeze fresh

food in the freezer compartment.

Control

10 * Depending on model and options
