Liebherr CN 4023 [3/16] External dimensions of the appli ance
![Liebherr CN 4023 [3/16] External dimensions of the appli ance](/views2/1317390/page3/bg3.png)
Foreseeable misuse
The following applications are expressly
prohibited:
-
Storage and cooling of medicines, blood
plasma, laboratory compounds or similar
materials and products subject to the Medical
Devices Directive 2007/47/EC
-
Use in potentially explosive areas
Improper use of the appliance can lead to
damage to or spoilage of the stored goods.
Climate rating definitions
The appliance is set to operate within specific
ambient temperature limits according to its
climate rating. The correct climate rating for
your appliance is indicated on the type plate.
Note
u
Compliance with the ambient temperatures
indicated is required, otherwise the cooling
performance is reduced.
Climate
rating
for ambient temperatures of
SN 10 °C to 32 °C
N 16 °C to 32 °C
ST 16 °C to 38 °C
T 16 °C to 43 °C
1.3 Conformity
The refrigerant circuit is tested for leakage. The appliance
complies with the relevant safety regulations and EC Directives
2006/95/EC, 2004/108/EC, 2009/125/EC and 2010/30/EU.
Note for test institutions:
Tests are to be carried out according to the applicable
standards and guidelines.
Preparation and testing of the appliances must be carried
out taking the manufacturer's loading plans and the
notes in the operating manual into account.
1.4 External dimensions of the appli-
ance
Fig. 2
Model
Height of appliance H
(mm)
CN(es/sl) 35.., CNP(esf/sl) 35.. 1817
CN 39.., CNP(esf) 39.. 2011
CN(es/esf/sl) 40..,
CNP(esf) 40..
2011
x
For appliances supplied with wall spacers, the measurement
increases by 35 mm (see 4.2) .
1.5 Saving energy
-
Always ensure good ventilation. Do not cover ventilation
openings or grille.
-
Always keep fan louvres clear.
-
Do not place appliance in areas of direct sunlight or next to a
stove, heater or similar object.
-
The energy consumption depends on the installation condi-
tions, e.g. the ambient temperature (see 1.2) .
-
Keep the time the appliance is open to a minimum.
-
The lower the temperature setting, the higher the power
consumption.
-
Store food logically. (see Appliance at a glance).
-
Ensure that all food is well packed and covered for storage.
This will prevent frost from forming.
-
Remove food as needed in order that it does not warm too
much.
-
First cool warm food to room temperature before storing it .
-
Defrost frozen food in the refrigerator.
-
Empty and switch off refrigerating unit for longer vacation
periods.
Accumulated dust increases the energy
consumption:
-
Once a year, dust the refrigerating unit
together with the metal grille of the heat
exchanger at the back of the appliance.
2 General safety information
Danger for the user:
-
This appliance can be used by children of 8
years old and over, and also by persons with
General safety information
* Depending on model and options 3
