Smeg ALFA 201 XМ [4/14] Instructions for the installer

Instructions for the installer

2. INSTALLATION OF THE OVEN

The oven must be set up on a perfectly flat surface and left standing

free. Make sure to allow enough room at the sides for easy access to the

terminal strip for connection of the power cable to mains.

Installation must be carried out by a qualified technician in compliance

with applicable regulations in force.

2.1 Electrical connection

Make sure that the power line voltage matches the specifications

indicated on the rating plate located to the rear of the oven. This rating

plate must never be removed.

For operation on 380-415V 3N

∼

: use

an H07RN-F-type five-core cable (5 x

1.5 mm

Make sure that plug and wall socket are of the same type and are in

conformity with regulations in force. Also check that the power supply

line is provided with adequate earthing. Avoid using adapters or

shunters.

In case of permanent connection, ensure that power cable is equipped

with an easily accessible omnipolar switch fitted in proximity to the

apparatus and with a gap between contacts equal to or greater than

3 mm.

The power supply connector on the back of the oven may be used only

for supplying the optional extractor hood, which has maximum power

absorption of 300W.
