10
GB
4.1 Turning the machine on
Provide the conservator with voltage by turn-
ing the main mains switch on.
Turn on the controller while keeping the
ON/OFF switch pressed , the controller
shows the welcome message, the version of
the software installed, the cabinet model and
then goes on to the following mask.
Message with compressor off and display of
inside cell temperature.
The cabinet has been prepared for function-
ing at the preset temperature.
Message with compressor on and display of
inside cell temperature.
The temperature on the display is the temper-
ature detected by the sensor inside the cell.
To turn off the controller, keep the ON/OFF
button pressed for five consecutive sec-
onds after which the controller enters low volt-
age stand-by function mode and will display
the following mask
The message displayed on the LCD screen in
the turning off phase is STAND-BY with blink-
ing cursor.
CAUTION to remove the voltage from the
controller switch the main mains switch.
4.2 Setting the language
Press the MENU button and with buttons or
go to MENU 7 LANGUAGE; the first lan-
guage is displayed when the ENTER but-
ton is pressed. The next time the button or
is pressed selects the languages available.
Menu 7
LANGUAGE
COOLING >>OK
CELL -12,5°C
PAUSE >>OK
CELL -14,5°C
AWAITED _
TURNING OFF
ON/OFF
Activation of continuous
operation recirculation
ventilation
Infrared
data receiver
Select the
menu
Decrease the
value
Confirm the entrance to the menu selected
or the value selected
Increase the value
