19
GB
INSTRUCTIONS BOOKLET
WARNINGS
A
This instruction booklet must be kept together with the appliance for future reference. If the
appliance is sold or consigned to other parties, check that the booklet is supplied with it, to
ensure that the new user has the correct information on the operation of the range hood and
is aware of the warnings. These warnings have been provided for the your safety and the
safety of others. As a result, please read them carefully before installing and operating the
appliance.
This appliance is not intended for use by young children or infirm persons unless they have
been adequately supervised by a responsible person to ensure that they can use the appliance
safely. Young children should be supervised to ensure they do not play with the appliance.
The appliance must be installed by qualified personnel, in accordance with the standards in
force. If the supply cord is damaged, it must be re-placed by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard. Any modifications that may be
required to the electrical system for the installation of the range hood must only be made by
qualified electricians.
It is dangerous to modify or attempt to modify the characteristics of this system. In the event of
malfunctions or if repairs are required to the appliance, do not attempt to solve the problems
directly.
Repairs performed by unqualified persons may cause damage. For all repair and other work on
the appliance, contact an authorised service/spare parts centre.
Always check that all the electrical parts (lights, exhaust device), are off when the appliance
is not being used. Read the entire instruction booklet before performing any operations on the
range hood.
The range hood must only be used for the exhaust of cooking fumes in home kitchens. The
manufacturer disclaims all liability for any other use of the appliance.
The maximum weight of any object placed above the hood, or hung to it (if possible) must
not exceed 1,5 kilos. After installing the stainless steel hood, clean it in order to remove any
residue of the protective glue, and stains of grease or oil. The manufacturer recommends its
cleaning cloth available for purchase. The manufacturer accepts no liability in case of dam-
age caused by the use of different detergent types.
It is absolutely forbidden to place limbs or any other part of the human body or animal body
in proximity to the range of the range hood’s mobile cart, defined by the frame that is fixed on
the base of the appliance (see illustration A).
Do not place cooking pans, cooking pan handles or any other object in the range of the range
hood’s mobile cart as specified above.
Be aware that accessible parts of the range hood may be hot during and after cooking.
The top glass VS (TG) and the light-shielding glass panel VL (LG) are fixed to the range hood’s
body with magnets. In case of detachment of VS VL (LG) from the range hood’s body due to
accidental causes, check its wholeness and position it back in its place. Otherwise, call
technical assistance.
There is a fire risk if cleaning is not carried out in accordance with the instructions
CAUTION: Accessible parts may become hot when used with cooking appliances.
Max. length screw for fixing the chimney is 10 mm (provided by the manufacturer).
WARNING: Failure to install the screws or fixing device in accordance with these instruc-
tions may result in electrical hazards.
