15
1. Two pole switch
2. Electrical connectors
3. Thermostat which shuts off at 57 degrees Celsius
4. Pressure sensing switch
5. Light bulb in switch
6. Pressure sensing switch
7. Power selector: Position 0 – off
Position 1 – low 2.0 KW
Position 2 – medium 3.5 KW
Position 3 – high 5.5 KW
8. Heating Element 1 - low 2.0 KW
9. Heating Element 2 – medium 3.5 KW
3. The temperature of the output water is regulated by “power selector” and external tap together
with combination of “rings” in the shower head or in “tap-goose”. On the diagram it is shown the
influence of the water flow, regulated by external tap and rings, on the temperature of the output
water.
Power selector is used for choosing one of the following variants:
0 – no heating,
1 - minimum heating level,
2 – medium heating level,
3 – maximum heating level
External tap is used to regulate the water flow. The smaller is the water flow; the higher is the
temperature of output water, and vice versa.
The combination of rings is used to regulate the water flow. During winter period only small open
ring with inlays should be used (very hot water). Small and medium rings with inlays should be
used in autumn and spring (medium water heating level). Small, medium, big open rings with
inlays should be used in summer (warm water).
4. In case the water flow is poor or the water is spraying in wrong direction, the rings should be
cleaned.
5. In case the quantity of input water is decreasing, it is necessary to clean the filter which is
installed at the water inlet.
Accessories
Model Accessories Shower Flexible pipe
1,5 м
Bracket
Set of
rubber
gaskets
"S" for
kitchen
ORION S
5.5
shower
+ + + +
sink
+ +
combined
+ + + + +
Additionally should be bought: an electric wire, a regular tap, a hose for the connection to the cold
water pipe.
