Form No. TF20M-0603 8
PROGRAMMING CONTROLLER
PROGRAMMING A SELECTION
The following terms are used when programming
the unit:
UP = Upper Power Value: Controls the power setting
on the upper heating element(s)
UT = Upper Time Value: Controls the time setting
on the upper heating element(s)
LP = Lower Power Value: Controls the power setting
on the lower heating element(s)
LT = Lower Time Value: Controls the time setting
on the lower heating element(s)
When the unit display shows a Power Value (UP
for upper heating zone or LP for lower heating zone)
the number indicates the value set at a percentage:
example P20 = 20%. These values are adjustable from
10-100% in 5% increments.
When the unit display shows a Time Value (UT
for upper heating zone or LT for lower heating zone)
the number indicates the time in seconds the heating
element will be on example T35 = 35 seconds. These
values are adjustable from 0-300 seconds.
1. Plug unit into a properly grounded electrical outlet
of the correct voltage, size and plug configuration.
(See Specifications for details.)
2. Turn power switch to the ON position. The unit will
make an audible beep, automatically go into preheat
and display will indicate StbY (Figure 7A).
After the preheat cycle is complete the unit will
display rEdY (Figure 7B). The unit is now ready
to be programmed.
3. With display showing rEdY, push and hold the
desired numbered Program Selection button, while
at the same time push and hold the Enter
button for 3 seconds
(Figure 7C).
4. Upper Power Value (UP): After 3 seconds,
the upper heat indicator will glow and the unit
will display P XX (Figure 7D). Press the UP
or DOWN arrow key until you reach
the desired setting.
5. Upper Time Value (UT): Press the ENTER
button and the unit will display T XX (Figure 7E).
Press the UP or DOWN arrow key until
you reach the desired setting.
6. Lower Power Value (LP): Press the ENTER
button and the unit will display P XX (Figure 7F).
Press the UP or DOWN arrow key until
you reach the desired setting.
7. Lower Time Value (LT): Press the Enter
button and the unit will display T XX (Figure 7G).
Press the UP or DOWN arrow key until
you reach the desired setting.
8. Press the Program Selection button to enter
all the settings into memory.
NOTE: If no adjustments are made within 15 seconds,
the controller will revert back to the normal mode
and will not accept any changes. Also, pressing
any of the numbered Program buttons after this
15 second interval will take the unit out of the
programming mode without accepting any changes.
9. If ready to finish food, place product in unit
to the back wall and press desired Program
Selection button.
10. Using a grease pencil or “China” pencil, record
the specific food entree on the control panel next
to the selected Program button.
11. Repeat steps 3 - 10 for the other Program buttons.
NOTE: All units keep the power and timing settings
in memory, even when the unit is turned off or is
unplugged from the power source.
NOTE: Models TF-2005, TF-2010 and TF-2045 do not
have lower heating elements but all steps must be
performed as if a bottom heating element is present. The
power (LP) and time (LT) values set for the bottom zone
must be less than the top zone for proper operation.
