Form No. TF20M-0603
10
PROGRAMMING CONTROLLER
IDLE MODE
The Thermo-Finisher
™
features an “Idle” mode. Once
the unit reaches the rEdY mode, the upper heating
element(s) automatically go into a programmed idle
power setting. (The display will still show rEdY during
the idle mode). The unit will stay in this mode until
one of the five Program buttons is pressed, or the unit
goes into auto-shut off.
NOTE: Begin by setting the idle mode power setting
at 20% and adjust the program accordingly to achieve
optimum performance.
To change the idle mode power setting, follow
these steps:
1. Press and hold the UP arrow while, at the same
time, press and hold the ENTER button
for thr
ee seconds. The display will show the current
programmed power value (Figure 8A).
2. To adjust the idle mode, press either the UP
or DOWN arrow until you reach the desired
setting (Figure 8B). Each time an arrow is pressed
the setting will change by ten.
3. To accept the new value, push the ENTER
button a second time (Figure 8C).
NOTE: If no adjustments are made within 15 seconds,
the controller goes back to its original settings without
accepting the change. Pushing any of the numbered
program buttons will also take the controller out of
programming mode without accepting the change.
AUTO-OFF MODE
The Thermo-Finisher features an Auto-Off mode that
turns all the elements off if the unit has not been used
for a programmed length of time. This feature can
be adjusted from 1 - 60 minutes in one minute
increments, or it can be set to never shut off by itself.
To change the Auto-Off mode to a new setting, make
sure unit is in rEdY mode and follow these steps:
1. Press and hold the DOWN arrow while
at the same time press and hold the ENTER
button for thr
ee seconds. The display will show
the current programmed Auto-Off value (Figure 9A).
2. To adjust the Auto-Off time push either the UP
or DOWN arrow until you reach the desired
setting (Figure 9B). The Auto-Off mode can
be adjusted from “0” (indicating unit will not turn
off) to 60 minutes until turn off time, in single
minute increments.
3. To accept the new Auto-Off time value, push the
ENTER button a second time (Figure 9C).
NOTE: If no adjustments are made within 15 seconds
the controller goes back to its original settings without
accepting the change. Pressing any of the numbered
buttons will also take the controller out of programming
mode without accepting the change. To get the unit
out of the Auto-Off Mode, push any one of the five
numbered program buttons and the unit will
begin operating.
PROGRAMMING HINTS:
• On menu items in which internal temperatures
are critical (such as chicken or pork), the primary
heat source comes from the bottom. On menu items
in which the surface temperatures are critical (such
as cheese melting), the primary heat source comes
from the top. See Recommended Food Finishing
Guide for specific menu examples.
• When performing product testing, heat three plates
with the same food product in succession. Adjust
program accordingly to achieve optimum
product temperature.
• When testing a menu item not listed in the
Recommended Food Finishing Guide start by
dividing the conventional cooking time by three and
use that number as your cooking time. Set top and
bottom heat at 50% and adjust accordingly if needed.
Program setting will vary based on model and food
product.
