27
www.hoshizaki-europe.com
IM Ice Makers - Self Contained
HOSHIZAKI–ISSUE 5
IM-21CNE
Production Capacity (kg/24h) Approx. 22
Storage Bin Capacity (kg) Approx. 11,5
Dimensions W x D x H (mm) 398 x 451 x 695
Electrical Supply 1/220 - 240V/50Hz
Electrical Capacity (kW) 0,24
Refrigerant R134a
Weight Gross / Net (kg) 39/34
Air Cooled Model(s) IM-21CNE
Type of Ice - Large Cube IM-21CNE
Optional Legs for IM-21CNE
Products available as 60hz models: IM-21CNE*
IM-30CNE
Production Capacity (kg/24h) Approx. 28
Storage Bin Capacity (kg) Approx. 11,5
Dimensions W x D x H (mm) 398 x 451 x 695 (Legs add 92-127mm)
Electrical Supply 1/220 - 240V/50Hz
Electrical Capacity (kW) 0,27
Refrigerant R134a
Weight Gross / Net (kg) 39/34
Air Cooled Model(s) IM-30CNE, IM-30CNE-25
Water Cooled Model(s) IM-30CWNE, IM-30CWNE-25
Type of Ice
Large Cube IM-30CNE, IM-30CWNE
Small Cube IM-30CNE-25, IM-30CWNE-25
Products available as 60hz models: IM-30CNE*, IM-30CWNE*
IM-45CNE
Production Capacity (kg/24h) Approx. 44
Storage Bin Capacity (kg) Approx. 15
Dimensions W x D x H (mm) 633 x 511 x 690 (Legs add 90-125mm)
Electrical Supply 1/220 - 240V/50Hz
Electrical Capacity (kW) 0,32
Refrigerant R134a
Weight Gross / Net (kg) 56/48
Air Cooled Model(s) IM-45CNE, IM-45CNE-25
Type of Ice
Large Cube IM-45CNE
Small Cube IM-45CNE-25
Products available as 60hz models: IM-45CNE*
*These products can be produced upon customer request. Please take longer lead times into consideration.
• Data shows the standard air cooled model • Production capacity (kg/24h): AT 10°C, WT 10°C.
