Hoshizaki IM-21CNE [49/74] Km ice makers self contained
![Hoshizaki IM-21CNE [49/74] Km ice makers self contained](/views2/1321201/page49/bg31.png)
50
www.hoshizaki-europe.com
KM Ice Makers - Self Contained
HOSHIZAKI–ISSUE 5
KM-50A
Production Capacity (kg/24h) Approx. 52
Storage Bin Capacity (kg) Approx. 23
Dimensions W x D x H (mm) 605 x 617 x 842
Electrical Supply 1/220 - 240V/50Hz
Electrical Capacity (kW) 0,303
Refrigerant R134a
Weight Gross / Net (kg) 58/46
Air Cooled Model(s) KM-50A
Type of Ice Crescent
Optional Instruction manual, scoop, adjustable bolt,
outlet hose
KM-75A
Production Capacity (kg/24h) Approx. 72
Storage Bin Capacity (kg) Approx. 40
Dimensions W x D x H (mm) 605 x 719 x 842
Electrical Supply 1/220 - 240V/50Hz
Electrical Capacity (kW) 0,412
Refrigerant R134a
Weight Gross / Net (kg) 64/51
Air Cooled Model(s) KM-75A
Type of Ice Crescent
Optional Instruction manual, scoop, adjustable bolt,
outlet hose
KM- 35A
Production Capacity (kg/24h) Approx. 36
Storage Bin Capacity (kg) Approx. 16
Dimensions W x D x H (mm) 452 x 617 x 842
Electrical Supply 1/220 - 240V/50Hz
Electrical Capacity (kW) 0,195
Refrigerant R134a
Weight Gross / Net (kg) 49/39
Air Cooled Model(s) KM-35A
Type of Ice Crescent
Optional Instruction manual, scoop, adjustable bolt,
outlet hose
• Production capacity (kg/24h): AT10°C, WT10°C.
