40
www.hoshizaki-europe.com
FM Ice Makers - Self Contained
HOSHIZAKI–ISSUE 5
FM-80KE/-N
Production Capacity (kg/24h) Approx. 85(F) / 65(N)
Storage Bin Capacity (kg) Approx. 26(F) / 32(N)
Dimensions W x D x H (mm) 640 x 600 x 800
Electrical Supply 1/220 - 240V/50Hz
Electrical Capacity (kW) 0,3
Refrigerant R134a
Weight Gross / Net (kg) 75/65
Air Cooled Model(s) FM-80KE, FM-80KE-N
Type of Ice
Flake Ice FM-80KE
Nugget Ice FM-80KE-N
FM-150KE/-N, CM-140KE
Production Capacity (kg/24h) Approx. 150(F) / 140(N) / 140(C)
Storage Bin Capacity (kg) Approx. 26(F) / 32(N) / 32(C)
Dimensions W x D x H (mm) 640 x 600 x 800
Electrical Supply 1/220 - 240V/50Hz
Electrical Capacity (kW) 0,64
Refrigerant R134a
Weight Gross / Net (kg) 82/71
Air Cooled Model(s) FM-150KE, FM-150KE-N, CM-140KE
Type of Ice
Flake Ice FM-150KE
Nugget Ice FM-150KE-N
Cubelet Ice CM-140KE
FM-150KE-50/-N
Production Capacity (kg/24h) Approx. 150(F) / 140(N)
Storage Bin Capacity (kg) Approx. 57(F) / 65(N)
Dimensions W x D x H (mm) 940 x 600 x 800
Electrical Supply 1/220 - 240V/50Hz
Electrical Capacity (kW) 0,64
Refrigerant R134a
Weight Gross / Net (kg) 94/81
Air Cooled Model(s) FM-150KE-50, FM-150KE-50-N
Type of Ice
Flake Ice FM-150KE-50
Nugget Ice FM-150KE-50-N
• Data shows the standard air cooled ake and nugget model • Production capacity (kg/24h): AT 10°C, WT 10°C.
