1 Remove the catechin air filter.

2 Remove the air cleaning filter.

REPLACEMENT OF THE AIR CLEANING FILTER

When the capacity is lowered because of dirt, etc., it is necessary to replace the air cleaning filter.

Air cleaning filter replacement (about once every year)

3 Attach a new air cleaning filter. Fix the filter

with the tabs securely.

4 Install the catechin air filter.

Be sure to install its both ends into the tabs

as shown below.

5 Securely close the front grille.

Air cleaning filter

• If the air cleaning filter is clogged, it may lower the unit’s capacity or cause condensation at the air outlet.

• The air cleaning filter is disposable. The standard usable term is about 1 year.

Optional parts Optional parts are available from your local dealer.

Name of parts

AIR CLEANING FILTER

(Anti-Allergy Enzyme Filter)

Parts number MAC-415FT-E

CLEANING THE

AIR CLEANING FILTER

Cleaning the air cleaning filter (about once every 3 months)

1 Remove the catechin air filter.

2 Remove the air cleaning filter.

3 Soak the filter together with its frame in luke-

warm water and wash it.

■ If the dirt is noticeable, use a solution of mild deter-

gent diluted in lukewarm water.

■ If hot water (50°C or more) is used, the filter may

be deformed.

■ Do not use a scrubbing brush or sponge. This may

damage the surface of the filter.

■ Do not use a chlorine detergent.

4 After rinsing with water/lukewarm water,

shake off the excess water and dry the filter

well in the shade.

■ Do not expose the filter to direct sunlight or heat

from a fire when drying it.

5 Attach the air cleaning filter. Fix the filter with

the tabs securely.

6 Install the catechin air filter. (Securely install

its tabs.)

7 Securely close the front grille.

Open the front grille

Catechin air filter

Open the front grille

Catechin air filter

Install.

Catechin air filter

Air cleaning filter

Catechin air filter

Air cleaning filter

Install.
