3、 When the 1 and 2 are both normal, then the components or integrated

circuit is damaged, the electric control board should be replaced.

continuous

lamp flicker

4times

temp. sensor and

humidity sensor

all fault

1、Check whether the resistance of the temperature sensor is normal,

otherwise replace it.

2、Check whether the humidity sensor is normal, otherwise replace it.

water full lamp

flicker （light

0.5SEC,

extinguish

0.5SEC）

water full of water

tank

Normal, discharge the water out, it will return to normal condition

automatically

五、inverter single split series

LED

running

lamp(flicke

r times)

timer

lamp(flicke

r times)

failure

The reason of fault and solution

F1 1 light communication fault

1、Check whether the connection of the outdoor unit and

indoor unit is one to one, otherwise connect the L, N

and communication line of the indoor unit and outdoor

unit one to one.

2、Measure whether the voltage between the zero line and

the communication line is 18V-30AC half-wave signal,

check whether the communication circuit on the indoor

and outdoor electric control board has been damaged,

otherwise replace it.

3、Check whether the LED on the outdoor power board has

been on, otherwise replace the electric control board.

4、Check whether the unit is abnormal caused by the

external interference, if it is, then find the interfering

source, and removes it.

F2 2 light

ambient temp.

sensor fault

1、 Check whether the resistance of sensor is normal,

otherwise replace it.

2、Check whether the sensor wire is short circuit or open

circuit, and whether the plug is well contacted, whether

there is welding off or rosin joint on the electric control

board, repair it if there is any above.

3、When the 1 and 2 are both normal, then the components

or integrated circuit is damaged, the electric control

board should be replaced.

F3 3 light

coil pipe temp.

sensor of indoor

unit

fault(inlet,middle

,outlet)

1、Check whether the resistance of sensor is normal,

otherwise replace it.

2、Check whether the sensor wire is short circuit or open

circuit, and whether the plug is well contacted, whether

there is welding off or rosin joint on the electric control

board, repair it if there is any above.

3、When the 1 and 2 are both normal, then the components

or integrated circuit is damaged, the electric control

board should be replaced.

F4 4 light fan motor of indoor

1、Check whether the contact of the plug of the motor wire
