OPERATING MANUAL FOR RETIGO HOLD-O-MAT
5
ver. EN-01/10/12
Repairs must only be carried out by authorised specialist
electricians or by our repair service.
1.4 Placement requirements
The Hold-o-mat can be used in many different parts
of the kitchen, preferably in a central location, not in a
remote corner. Thanks to its ease of installation (no
water, drainage or air extraction connections), the unit
can be placed anywhere. Ensure, however, that the
power supply is 230V/50/60Hz.
If the Hold-o-mat is built-in, sufcient cool air should
be allowed to circulate.
The Hold-o-mat does not have to be tied to one
location. It can be used in a variety of places such as
the kitchen, lounge, and for parties etc. If the unit is
permanently installed in one place and cannot be
disconnected from the mains by a switch, the plug on
the power cable must remain accessible.
Note: Valid for Hold-o-mat Big - Use the carrying handles only
when the total weight (unit-weight 41 kg plus content weight) is less
than 70 kg. Use all four handles equally and avoid jerky movements.
If the unit is permanently installed in one place and
cannot be disconnected from the mains by a switch,
the plug on the power cable must remain accessible.
Basic instructions for installation:
– Place the unit on sturdy surface.
– Ambient temperature + 10°C to + 40°C. Do not place
the unit next to or on top of hot surfaces (radiators or hot
plates): there is a danger of melting, re or short circuit!
– Never bring the unit into contact with water or other
liquids as there is a danger of short-circuit!
– To ensure adequate air circulation, all sides of the
unit must be kept a minimum of 10 mm from walls and
other objects.
Never use a damaged unit.
1.5 Gastrocontainers
Suitable GN
- stailess steel, enamelled
- recommended size: 1/1, 2/3
- recommended depth: 65 and 100 mm
- other GN offeres by Retigo company
Unsuitable GN
- Plastic, synthetic and other non-heat resistant
containers.
Never use a damaged unit. Please note that the
outside of the unit must not be sprayed with
excessive amounts of water or other liquids.
Repairs must only be carried out by authorised
specialist electricians or by our repair service.
2. Content of packaging
The packge contens: 1 unit, 2 side rails, 1 set of
operating instructions, 2 power cables (1 x EU/1 x CH).
Check the package contents. If parts are missing,
return immediately to your supplier.
The product has been supplied to you in cardboard
packaging. Dispose of the packaging properly or return
it to your supplier.
Check the unit for visible signs of damage. Do not
use the unit if defective. Report the damage immediately
to your supplier.
3. Rehinging the door
The door can be easily rehinged within 10 to 15
minutes. Because the unit casing has to be opened for
this purpose, current-carrying parts will be exposed.
The door may only be rehinged by specialist personnel
(qualied electrician, service tter, Retigo authorised
sales person), and only in accordance with the customer
service instruction provided for this purpose.
How to change the door opening:
- Withdraw the mains plug from the socket. Withdraw
the plug from the equipment socket of the unit controller.
Store the power cable where it is inaccessible to other
persons for the duration of the customer service work.
- Remove the two lower hinge screws and unhinge
the door.
- Remove the screw on the opposite side which
holds the casing in place at the bottom front.
- At the rear of the unit, remove the six screws
attaching the housing to the rear wall.
- Slide the casing towards the rear and at the front of
the unit press the main insulation slightly backwards in
order to gain access to the two earth plates on which
the four magnets are located.
