OPERATING MANUAL FOR RETIGO HOLD-O-MAT
7
ver. EN-01/10/12
5. Operating of Retigo Hold-o-mat 1/1 Standard (without temperature core probe)
5.1 Control panel
Main switch - on/off Heat
indicator
Higher
temp.
Lower
temp.
Temp. indicator
5.2 Basic operating instructions
5.2.1 Switching on
- Press the button to switch on.
5.2.2 Temperature setting
- The indicator always shows the actual
temperature. By pushing an arrow button
once, the desired temperature is displayed for two
seconds. Then the indicator returns to showing the
actual temperature.
By pressing the buttons again while the desired
temperature is displayed, the desired temperature can
be increased or decreased.
Pressing both buttons together automatically sets
the the most important temperature of 68°C. The
desired temperature is reached within 20 to 40 minutes,
depending on what temperature has been chosen.
The Hold-o-mat is designed to respond to this slowly,
but this ensures that the desired temperature is
maintained within a +/- 1°C tolerance.
The warming-up time can be shortened by setting a
higher temperature than actually required. Do not forget,
however, to lower the temperature in time (about
6–10°C below the desired temperature), otherwise the
unit will get too warm.
If the Hold-o-mat exceeds the desired temperature
by 5°C or more, the indicator ashes to warn kitchen
staff. To cool the unit slowly, leave the door open slightly
longer. (Thanks to its excellent insulation, this takes
somewhat longer than with other units.)
The desired temperature can be set to the degree
in a range from 50°C to 120°C. The PT 500 and excellent
electronics, which approach the desired temperature
slowly step by step (a timing pulse system), guarantee
+/- 1°C accuracy.
5.2.3 Switching off
- Press the button to switch the Hold-o-mat off.
Please do not forget to clean the unit after use
as outlined in the section „Maintanance“.
5.3 Technical specication
Model: Hold-o-mat
Product no.: 673
Power supply: 230V, 50/60Hz, 1 kW
Fuse: 10 A
Storage temperature: 0°C - + 50°C
Ambient temperature: +10°C - + 40 °C
Temperature range: +20°C - +120 °C
Dimensions (WxHxD): 415 x 343 x 675 mm
Weight: 24 kg
Average power
consumption: cca. 300 W/h
Equivalent noise level: 70 dB(A)
Safety gap from walls and other equipment at least
10 mm.
