2. About the product
・The outdoor unit described in this manual is air-conditioning equipment that is designed only for human comfort.
・The numeric values in the unit model name (e.g., PUHY-EP***-YLM-A) indicate the capacity index of the unit.
・This unit uses R410A refrigerant.
3. Combination of outdoor units
Outdoor unit model Combination of outdoor units
PUHY-EP200YLM-A(-BS) - - -
PUHY-EP250YLM-A(-BS) - - -
PUHY-EP300YLM-A(-BS) - - -
PUHY-EP350YLM-A(-BS) - - -
PUHY-EP400YLM-A(-BS) - - -
PUHY-EP450YLM-A(-BS) - - -
PUHY-EP500YLM-A(-BS) - - -
PUHY-EP500YSLM-A(-BS) PUHY-EP250YLM-A(-BS) PUHY-EP250YLM-A(-BS) -
PUHY-EP550YSLM-A(-BS) PUHY-EP300YLM-A(-BS) PUHY-EP250YLM-A(-BS) -
PUHY-EP600YSLM-A(-BS) PUHY-EP300YLM-A(-BS) PUHY-EP300YLM-A(-BS) -
PUHY-EP650YSLM-A(-BS) PUHY-EP250YLM-A(-BS) PUHY-EP200YLM-A(-BS) PUHY-EP200YLM-A(-BS)
PUHY-EP700YSLM-A(-BS) PUHY-EP300YLM-A(-BS) PUHY-EP200YLM-A(-BS) PUHY-EP200YLM-A(-BS)
PUHY-EP750YSLM-A(-BS) PUHY-EP300YLM-A(-BS) PUHY-EP250YLM-A(-BS) PUHY-EP200YLM-A(-BS)
PUHY-EP800YSLM-A(-BS) PUHY-EP300YLM-A(-BS) PUHY-EP300YLM-A(-BS) PUHY-EP200YLM-A(-BS)
PUHY-EP850YSLM-A(-BS) PUHY-EP300YLM-A(-BS) PUHY-EP300YLM-A(-BS) PUHY-EP250YLM-A(-BS)
PUHY-EP900YSLM-A(-BS) PUHY-EP300YLM-A(-BS) PUHY-EP300YLM-A(-BS) PUHY-EP300YLM-A(-BS)
PUHY-EP950YSLM-A(-BS) PUHY-EP350YLM-A(-BS) PUHY-EP300YLM-A(-BS) PUHY-EP300YLM-A(-BS)
PUHY-EP1000YSLM-A(-BS) PUHY-EP400YLM-A(-BS) PUHY-EP300YLM-A(-BS) PUHY-EP300YLM-A(-BS)
PUHY-EP1050YSLM-A(-BS) PUHY-EP400YLM-A(-BS) PUHY-EP350YLM-A(-BS) PUHY-EP300YLM-A(-BS)
PUHY-EP1100YSLM-A(-BS) PUHY-EP400YLM-A(-BS) PUHY-EP350YLM-A(-BS) PUHY-EP350YLM-A(-BS)
PUHY-EP1150YSLM-A(-BS) PUHY-EP450YLM-A(-BS) PUHY-EP350YLM-A(-BS) PUHY-EP350YLM-A(-BS)
PUHY-EP1200YSLM-A(-BS) PUHY-EP450YLM-A(-BS) PUHY-EP400YLM-A(-BS) PUHY-EP350YLM-A(-BS)
PUHY-EP1250YSLM-A(-BS) PUHY-EP450YLM-A(-BS) PUHY-EP450YLM-A(-BS) PUHY-EP350YLM-A(-BS)
PUHY-EP1300YSLM-A(-BS) PUHY-EP450YLM-A(-BS) PUHY-EP450YLM-A(-BS) PUHY-EP400YLM-A(-BS)
PUHY-EP1350YSLM-A(-BS) PUHY-EP450YLM-A(-BS) PUHY-EP450YLM-A(-BS) PUHY-EP450YLM-A(-BS)
* "Twinning Kit" is required to connect combination units on site.
