GB
GB-9
WT07281X03
4. Specifications
Model
PUHY-EP200YLM-A PUHY-EP250YLM-A PUHY-EP300YLM-A PUHY-EP350YLM-A PUHY-EP400YLM-A
Sound level (50/60 Hz) 57 dB <A> 60 dB <A> 61 dB <A> 61 dB <A> 62.5 dB <A>
External static pressure 0 Pa*
2
Indoor unit
Total capacity 50% to 130%*
1
Model 15 to 250
Quantity 1 to 17 1 to 21 1 to 26 1 to 30 1 to 34
Temperature
range (Cooling)
Indoor W.B. +15.0°C to +24.0°C (+59.0°F to +75.0°F)
Outdoor D.B. -5.0°C to +52.0°C (+23.0°F to +126.0°F)
Temperature
range (Heating)
Indoor D.B. +15.0°C to +27.0°C (+59.0°F to +81.0°F)
Outdoor W.B. -20.0°C to +15.5°C (-4.0°F to +60.0°F)
Model
PUHY-EP450YLM-A PUHY-EP500YLM-A PUHY-EP500YSLM-A PUHY-EP550YSLM-A PUHY-EP600YSLM-A
Sound level (50/60 Hz) 63 dB <A> 63.5 dB <A> 63 dB <A> 63.5 dB <A> 64 dB <A>
External static pressure 0 Pa*
2
Indoor unit
Total capacity 50% to 130%*
1
Model 15 to 250
Quantity 1 to 39 1 to 43 1 to 43 2 to 47 2 to 50
Temperature
range (Cooling)
Indoor W.B. +15.0°C to +24.0°C (+59.0°F to +75.0°F)
Outdoor D.B. -5.0°C to +52.0°C (+23.0°F to +126.0°F)
Temperature
range (Heating)
Indoor D.B. +15.0°C to +27.0°C (+59.0°F to +81.0°F)
Outdoor W.B. -20.0°C to +15.5°C (-4.0°F to +60.0°F)
Model
PUHY-EP650YSLM-A PUHY-EP700YSLM-A PUHY-EP750YSLM-A PUHY-EP800YSLM-A PUHY-EP850YSLM-A
Sound level (50/60 Hz) 63 dB <A> 63.5 dB <A> 64.5 dB <A> 65 dB <A> 65.5 dB <A>
External static pressure 0 Pa*
2
Indoor unit
Total capacity 50% to 130%*
1
Model 15 to 250
Quantity 2 to 50 2 to 50 2 to 50 2 to 50 2 to 50
Temperature
range (Cooling)
Indoor W.B. +15.0°C to +24.0°C (+59.0°F to +75.0°F)
Outdoor D.B. -5.0°C to +52.0°C (+23.0°F to +126.0°F)
Temperature
range (Heating)
Indoor D.B. +15.0°C to +27.0°C (+59.0°F to +81.0°F)
Outdoor W.B. -20.0°C to +15.5°C (-4.0°F to +60.0°F)
Model
PUHY-EP900YSLM-A PUHY-EP950YSLM-A
PUHY-EP1000YSLM-A PUHY-EP1050YSLM-A PUHY-EP1100YSLM-A
Sound level (50/60 Hz) 66 dB <A> 66 dB <A> 66.5 dB <A> 66.5 dB <A> 66.5 dB <A>
External static pressure 0 Pa*
2
Indoor unit
Total capacity 50% to 130%*
1
Model 15 to 250
Quantity 2 to 50 2 to 50 2 to 50 3 to 50 3 to 50
Temperature
range (Cooling)
Indoor W.B. +15.0°C to +24.0°C (+59.0°F to +75.0°F)
Outdoor D.B. -5.0°C to +52.0°C (+23.0°F to +126.0°F)
Temperature
range (Heating)
Indoor D.B. +15.0°C to +27.0°C (+59.0°F to +81.0°F)
Outdoor W.B. -20.0°C to +15.5°C (-4.0°F to +60.0°F)
Model
PUHY-EP1150YSLM-A PUHY-EP1200YSLM-A PUHY-EP1250YSLM-A PUHY-EP1300YSLM-A PUHY-EP1350YSLM-A
Sound level (50/60 Hz) 66.5 dB <A> 67 dB <A> 67.5 dB <A> 68 dB <A> 68 dB <A>
External static pressure 0 Pa*
2
Indoor unit
Total capacity 50% to 130%*
1
Model 15 to 250
Quantity 3 to 50 3 to 50 3 to 50 3 to 50 3 to 50
Temperature
range (Cooling)
Indoor W.B. +15.0°C to +24.0°C (+59.0°F to +75.0°F)
Outdoor D.B. -5.0°C to +52.0°C (+23.0°F to +126.0°F)
Temperature
range (Heating)
Indoor D.B. +15.0°C to +27.0°C (+59.0°F to +81.0°F)
Outdoor W.B. -20.0°C to +15.5°C (-4.0°F to +60.0°F)
*1 The maximum total capacity of indoor units operating simultaneously is 130%.
*2 To enable the high static pressure setting, set the dipswitch on the main board as follows.
SW6-4: ON
SW6-5: OFF (60 Pa) or ON (30 Pa)
