Pipes A, A1, A2, A3, A4 [mm]
Unit model
Combination unit Pipe A Pipe A
1*
3
Pipe A2*
3
Pipe A3*
3
Pipe A4
Unit 1 Unit 2 Unit 3 Liquid Gas Liquid Gas Liquid Gas Liquid Gas Liquid Gas
EP200YLM-A - - - ø9.52 ø22.2 - - - - - - - -
EP250YLM-A - - - ø9.52*
1
ø22.2 - - - - - - - -
EP300YLM-A - - - ø9.52*
2
ø28.58 - - - - - - - -
EP350YLM-A - - - ø12.7 ø28.58 - - - - - - - -
EP400YLM-A - - - ø12.7 ø28.58 - - - - - - - -
EP450YLM-A - - - ø15.88 ø28.58 - - - - - - - -
EP500YLM-A - - - ø15.88 ø28.58 - - - - - - - -
EP500YSLM-A EP250 EP250 - ø15.88 ø28.58 ø9.52 ø22.2 ø9.52 ø22.2 - - - -
EP550YSLM-A EP300 EP250 - ø15.88 ø28.58 ø12.7 ø28.58 ø9.52 ø22.2 - - - -
EP600YSLM-A EP300 EP300 - ø15.88 ø28.58 ø12.7 ø28.58 ø12.7 ø28.58 - - - -
EP650YSLM-A EP250 EP200 EP200 ø15.88 ø28.58 ø9.52 ø22.2 ø9.52 ø22.2 ø9.52 ø22.2 ø19.05 ø34.93
EP700YSLM-A EP300 EP200 EP200 ø19.05 ø34.93 ø12.7 ø28.58 ø9.52 ø22.2 ø9.52 ø22.2 ø19.05 ø34.93
EP750YSLM-A EP300 EP250 EP200 ø19.05 ø34.93 ø12.7 ø28.58 ø9.52 ø22.2 ø9.52 ø22.2 ø19.05 ø34.93
EP800YSLM-A EP300 EP300 EP200 ø19.05 ø34.93 ø12.7 ø28.58 ø12.7 ø28.58 ø9.52 ø22.2 ø19.05 ø34.93
EP850YSLM-A EP300 EP300 EP250 ø19.05 ø41.28 ø12.7 ø28.58 ø12.7 ø28.58 ø9.52 ø22.2 ø19.05 ø34.93
EP900YSLM-A EP300 EP300 EP300 ø19.05 ø41.28 ø12.7 ø28.58 ø12.7 ø28.58 ø12.7 ø28.58 ø19.05 ø34.93
EP950YSLM-A EP350 EP300 EP300 ø19.05 ø41.28 ø12.7 ø28.58 ø12.7 ø28.58 ø12.7 ø28.58 ø19.05 ø34.93
EP1000YSLM-A EP400 EP300 EP300 ø19.05 ø41.28 ø15.88 ø28.58 ø12.7 ø28.58 ø12.7 ø28.58 ø19.05 ø34.93
EP1050YSLM-A EP400 EP350 EP300 ø19.05 ø41.28 ø15.88 ø28.58 ø12.7 ø28.58 ø12.7 ø28.58 ø19.05 ø34.93
EP1100YSLM-A EP400 EP350 EP350 ø19.05 ø41.28 ø15.88 ø28.58 ø12.7 ø28.58 ø12.7 ø28.58 ø19.05 ø34.93
EP1150YSLM-A EP450 EP350 EP350 ø19.05 ø41.28 ø15.88 ø28.58 ø12.7 ø28.58 ø12.7 ø28.58 ø19.05 ø34.93
EP1200YSLM-A EP450 EP400 EP350 ø19.05 ø41.28 ø15.88 ø28.58 ø15.88 ø28.58 ø12.7 ø28.58 ø19.05 ø34.93
EP1250YSLM-A EP450 EP450 EP350 ø19.05 ø41.28 ø15.88 ø28.58 ø15.88 ø28.58 ø12.7 ø28.58 ø19.05 ø34.93
EP1300YSLM-A EP450 EP450 EP400 ø19.05 ø41.28 ø15.88 ø28.58 ø15.88 ø28.58 ø15.88 ø28.58 ø19.05 ø34.93
EP1350YSLM-A EP450 EP450 EP450 ø19.05 ø41.28 ø15.88 ø28.58 ø15.88 ø28.58 ø15.88 ø28.58 ø19.05 ø34.93
Pipes A, A1, A2, A3, A4 [in]
Unit model
Combination unit Pipe A Pipe A
1*
3
Pipe A2*
3
Pipe A3*
3
Pipe A4
Unit 1 Unit 2 Unit 3 Liquid Gas Liquid Gas Liquid Gas Liquid Gas Liquid Gas
EP200YLM-A - - - ø3/8 ø7/8 - - - - - - - -
EP250YLM-A - - - ø3/8*
1
ø7/8 - - - - - - - -
EP300YLM-A - - - ø3/8*
2
ø1-1/8 - - - - - - - -
EP350YLM-A - - - ø1/2 ø1-1/8 - - - - - - - -
EP400YLM-A - - - ø1/2 ø1-1/8 - - - - - - - -
EP450YLM-A - - - ø5/8 ø1-1/8 - - - - - - - -
EP500YLM-A - - - ø5/8 ø1-1/8 - - - - - - - -
EP500YSLM-A EP250 EP250 - ø5/8 ø1-1/8 ø3/8 ø7/8 ø3/8 ø7/8 - - - -
EP550YSLM-A EP300 EP250 - ø5/8 ø1-1/8 ø1/2 ø1-1/8 ø3/8 ø7/8 - - - -
EP600YSLM-A EP300 EP300 - ø5/8 ø1-1/8 ø1/2 ø1-1/8 ø1/2 ø1-1/8 - - - -
EP650YSLM-A EP250 EP200 EP200 ø5/8 ø1-1/8 ø3/8 ø7/8 ø3/8 ø7/8 ø3/8 ø7/8 ø3/4 ø1-3/8
EP700YSLM-A EP300 EP200 EP200 ø3/4 ø1-3/8 ø1/2 ø1-1/8 ø3/8 ø7/8 ø3/8 ø7/8 ø3/4 ø1-3/8
EP750YSLM-A EP300 EP250 EP200 ø3/4 ø1-3/8 ø1/2 ø1-1/8 ø3/8 ø7/8 ø3/8 ø7/8 ø3/4 ø1-3/8
EP800YSLM-A EP300 EP300 EP200 ø3/4 ø1-3/8 ø1/2 ø1-1/8 ø1/2 ø1-1/8 ø3/8 ø7/8 ø3/4 ø1-3/8
EP850YSLM-A EP300 EP300 EP250 ø3/4 ø1-5/8 ø1/2 ø1-1/8 ø1/2 ø1-1/8 ø3/8 ø7/8 ø3/4 ø1-3/8
EP900YSLM-A EP300 EP300 EP300 ø3/4 ø1-5/8 ø1/2 ø1-1/8 ø1/2 ø1-1/8 ø1/2 ø1-1/8 ø3/4 ø1-3/8
EP950YSLM-A EP350 EP300 EP300 ø3/4 ø1-5/8 ø1/2 ø1-1/8 ø1/2 ø1-1/8 ø1/2 ø1-1/8 ø3/4 ø1-3/8
EP1000YSLM-A EP400 EP300 EP300 ø3/4 ø1-5/8 ø5/8 ø1-1/8 ø1/2 ø1-1/8 ø1/2 ø1-1/8 ø3/4 ø1-3/8
EP1050YSLM-A EP400 EP350 EP300 ø3/4 ø1-5/8 ø5/8 ø1-1/8 ø1/2 ø1-1/8 ø1/2 ø1-1/8 ø3/4 ø1-3/8
EP1100YSLM-A EP400 EP350 EP350 ø3/4 ø1-5/8 ø5/8 ø1-1/8 ø1/2 ø1-1/8 ø1/2 ø1-1/8 ø3/4 ø1-3/8
EP1150YSLM-A EP450 EP350 EP350 ø3/4 ø1-5/8 ø5/8 ø1-1/8 ø1/2 ø1-1/8 ø1/2 ø1-1/8 ø3/4 ø1-3/8
EP1200YSLM-A EP450 EP400 EP350 ø3/4 ø1-5/8 ø5/8 ø1-1/8 ø5/8 ø1-1/8 ø1/2 ø1-1/8 ø3/4 ø1-3/8
EP1250YSLM-A EP450 EP450 EP350 ø3/4 ø1-5/8 ø5/8 ø1-1/8 ø5/8 ø1-1/8 ø1/2 ø1-1/8 ø3/4 ø1-3/8
EP1300YSLM-A EP450 EP450 EP400 ø3/4 ø1-5/8 ø5/8 ø1-1/8 ø5/8 ø1-1/8 ø5/8 ø1-1/8 ø3/4 ø1-3/8
EP1350YSLM-A EP450 EP450 EP450 ø3/4 ø1-5/8 ø5/8 ø1-1/8 ø5/8 ø1-1/8 ø5/8 ø1-1/8 ø3/4 ø1-3/8
*1 Use the ø12.7 (ø1/2) pipe if the piping length from the outdoor unit to the farthest indoor unit is 90 m (295 ft) or longer.
*2 Use the ø12.7 (ø1/2) pipe if the piping length from the outdoor unit to the farthest indoor unit is 40 m (131 ft) or longer.
*3 If the combination units 1, 2, and 3 are in a different order as listed in the table, make sure to use the pipes of appropriate size for the situation.
*4 If the pipe length after the first branching point exceeds 40 m (131 ft) (≤ 90 m (295 ft)), use the one size larger liquid pipe for all pipes from indoor
units to the first branch.
*5 When the vertical separation between the indoor units is 15 m (49 ft) (≤ 30 m (98 ft)), use the one size larger liquid pipe for all pipes from the
lower indoor units to the first branch.
Pipes B,C,D [mm (in)] Pipes a,b,c,d,e [mm (in)]
Total capacity of indoor units
Pipe
Capacity index of indoor unit
Pipe
Liquid Gas Liquid Gas
140 or below ø9.52 (ø3/8) ø15.88 (ø5/8) 20, 25, 32, 40, 50 ø6.35 (ø1/4) ø12.7 (ø1/2)
141 to 200 ø9.52 (ø3/8) ø19.05 (ø3/4) 63, 71, 80, 100, 125, 140 ø9.52 (ø3/8) ø15.88 (ø5/8)
201 to 300 ø9.52 (ø3/8) ø22.2 (ø7/8) 200 ø9.52 (ø3/8) ø19.05 (ø3/4)
301 to 400 ø12.7 (ø1/2) ø28.58 (ø1-1/8) 250 ø9.52 (ø3/8) ø22.2 (ø7/8)
401 to 650 ø15.88 (ø5/8) ø28.58 (ø1-1/8)
651 to 800 ø19.05 (ø3/4) ø34.93 (ø1-3/8)
801 or above ø19.05 (ø3/4) ø41.28 (ø1-5/8)
