Mitsubishi Electric PEFY-P32VMA-E [5/21] Fig 9 fig 9

F Use PG bushing to keep the weight of the cable and external force from being

applied to the power supply terminal connector. Use a cable tie to secure the

cable.

G Power source wiring

H Use ordinary bushing

I Transmission wiring

J Te r minal block for power source

K Te r minal block for indoor transmission

L Te r minal block for remote controller

A Te r minal block

B Round terminal

C Shield wire

D The earth wire from two cables are connected together to the S terminal. (Dead-end connection)

E Insulation tape (To keep the earth wire of the shielded cable from coming in contact with the transmis-

sion terminal)

9.3

[Fig. 9.3.3]

[Fig. 9.3.4]

[Fig. 9.3.5]

C Te r minal box

D Knockout hole

E Remove

A Screw holding cover (1pc)

B Cover

[Fig. 9.3.1] [Fig. 9.3.2]

A Non-polarized

B TB15

C Remote Controller

D TB5

[Fig. 9.2.3] [Fig. 9.2.4]

DC10~13V

DC24~30V

(A, B)

M2 SM1

9.5

[Fig. 9.5.1]

9.2

SWA

SW5

SW14

SW12

SWC

SW11
