5
GB
D
F
INL
E
PGRRUTR
A Hora actual/Hora do temporizador
B Indicador de controlo centralizado
C Indicador de temporizador OFF
D Indicador de modo do temporizador
E
Visor do modo de funcionamento:
COOL, DRY, AUTO, FAN, HEAT
F Indicador do modo de funcionamento G Temperatura predefinida
H Indicador de corrente I Aba
J Ventilação K Sinal do filtro
L Posição do sensor M Temperatura ambiente
N Regulação da palheta O Velocidade da ventoinha
P Lâmpada de funcionamento
A Huidige tijd/Timertijd
B Indicatielampje voor centraal regelen
C Indicatielampje timer UIT
D Indicatielampje timermodus
E
Werkingsstand:
COOL, DRY, AUTO, FAN, HEAT
F Indicatielampje functiemodus G Vooraf ingestelde temperatuur
H Voedingsindicatielampje I Jaloezie
J Ventilatie K Filterteken
L Plaats van sensor M Kamertemperatuur
N Instelling ventilatorblad O Ventilatorsnelheid
P Bedrijfslamp
A Heure réelle/heure de la minuterie
B Témoin de commande à distance centralisée
C Témoin de minuterie OFF
D Témoin de mode de minuterie
E
Affichage du mode de fonctionnement
: FROID, DESHU, AUTO, VENTILATION,
CHAUD
F Témoin de mode de fonctionnement G Température prédéfinie
H Témoin d’alimentation I Louvre
J Ventilation K Signe du filtre
L Position du capteur M Température de la pièce
N Réglage des ailettes O Vitesse du ventilateur
P Témoin de fonctionnement
A Ora corrente/Timer
B Indicatore comando centralizzato
C Indicatore Timer non attivato
D Indicatore modalità Timer
E
Visualizzazione modalità di funzionamento
: COOL, DRY, AUTO,
VENTILAZIONE, HEAT
F Indicatore modalità funzione G Preimpostazione temperatura
H Indicatore alimentazione I Deflettore
J Ventilazione K Simbolo del filtro
L Posizione del sensore M Temperatura ambiente
N Impostazione lamelle O Velocità di ventilazione
P Spia di funzionamento
A Hora actual/hora del temporizador
B Indicador de control centralizado
C Indicador de desconexión del temporizador
D Indicador de modo del temporizador
E
Pantalla de modo de funcionamiento
: FRÍO, DESHUMIDIFICACION,
AUTOMÁTICO, VENTILACIÓN,
CALOR
F Indicador de modo de función G Temperatura prefijada
H Indicador de encendido I Rejilla
J Ventilación K Señalización de filtro
L Posición de sensor M Temperatura de la habitación
N Ajuste de deflectores O Velocidad del ventilador
P Lámpara de funcionamiento
A Aktuelle Uhrzeit/Timer-Zeit
B Anzeige für Zentralsteuerung
C Timer-OFF-Anzeige
D Anzeige des Timer-Modus
E Betriebsartenanzeige: Kühlen, Trocknen, AUTO, Lüfter, Heizen
F Anzeige des Funktionsmodus G Voreingestellte Temperatur
H Netzanzeige I Luftklappe
J Ventilation K Filtersymbol
L Sensorposition M Raumtemperatur
N Flügeleinstellung O Ventilatorgeschwindigkeit
P Betriebsanzeige
Remote controller-Display
Fernbedienung-Anzeige
Affichage Commande à distance
Controlador remoto-Indicador
Display dell’unità del comando a distanza
Display afstandbediening
Visualização do controlo remoto
E
I
NL
GB
D
F P
A Current time/Timer time
B Centralized control indicator
C Timer OFF indicator
D Timer mode indicator
E Operation mode display: COOL, DRY, AUTO, FAN, HEAT
F Function mode indicator G Preset temperature
H Power indicator I Louver
J Ventilation K Filter sign
L Sensor position M Room temperature
N Vane setting O Fan speed
P Operation lamp
ON/OFF
ERROR CODE
TIME
ON
OFF
Hr
AFTER
SUN MON TUE WED THU FRI SAT
TIMER
AFTER
ONLY 1Hr.
˚C˚F
WEEKLY
SIMPLE
AUTO OFF
FILTER
FUNCTION
˚C˚F
TEMP.
E
B
C
H
IN MGPJD
L
A
O
F
K
WT04883X02_front.p65 07.8.20, 6:56 PM5
