Norpe EUROMAX 195-M-ED-EC-HE BG0088 [12/106] Cleaning condenser

3. Allow the cabinet to reach the ambient temperature.

4. Remove any debris.

Do not use picks or sharp tools to remove ice from the evaporator. Damage to the coil may

lead to refrigerant leakage.

5. Inspect for drain water and remove it, if there is any.

6. Clean the interior surfaces of the cabinet with a mild liquid detergent (non-toxic, pH 6-8) and

dry the surfaces carefully using a clean towel.

7. When cleaning is completed, start up the cabinet.

See section Starting up.

Check at regular intervals also that

• the operating noise of the cabinet is normal,

• the evaporator is clean and

• the inlet and outlet grids are not obstructed or dirty.

Clean the drain sump located in the machinery compartment. Inadequate or

infrequent cleaning may shorten the service life of the electric heater / hot

gas piping for the drain sump. Detergent residues must be cleaned without

delay from the tray.

NOTE

In the event of a refrigerant leakage all products displayed in the cabinet must

be disposed of and then the cabinet must be cleaned.

NOTE

5.1. Cleaning condenser

Check once a month, or more often if necessary, that the condenser is clean.

Carry out the following procedures when necessary.

1. Vacuum the condenser fins and check that the spaces between the fins are unobstructed.

2. Pull the top edge of the plate outwards and turn the plate downwards, as

indicated in the enclosed drawing.

If the controller unit indicates high pressure in the condenser, check the

condenser and clean it, if necessary. If the cabinet still doesn't function

normally after this procedure, contact service.

When the cabinet is disconnected from the mains

supply, the sump heater or pump will not operate

and drain water or cleaning liquid may fill the

evaporation sump.

NOTE

The condensing unit is located on top of the

cabinet.

NOTE

Version 05/2015

ENGLISH
