129
RBC-U31PG (W, WS)-E, RBC-U31PGS (W, WS)-E
Location
Parts No. Description
No.
301 43409207 Grille, Air Inlet
302 43480017 Air Filter, ABS + PPNET
303 4302D003 Motor, Louver, MP24Z3N
304 43407145 Outlet, Air Form, PS-F
305 43407146 Outlet, Air Form, PS-F
306 43409212 Louver, ABS
307 43409216 Louver, ABS
308 43401037 Cover, Panel Ass’y
309 43401041 Cover, Panel Ass’y
310 43401043 Cover, Panel Ass’y
311 43401047 Cover, Panel Ass’y
312 43407148 Plate, Fix, Panel
313 43407149 Plate, Fix, Panel
314 43407150 Hook, ABS
315 43407154 Cap, AXIS, POM
316 43403010 Cover Ass’y, Motor
317 43403011 Cover Ass’y
318 43403012 Cover Ass’y
319 43407155 Fix, Motor, ABS
320 43407156 Fix, Motor, ABS
321 43460125 Lead, Motor
322 43400077 Panel, Front, PS (W)
323 43109423 Louver, ABS
324 43109424 Louver, ABS
Model Name RBC-U31
U31PG(W)-E U31PG(WS)-E U31PGS(W)-E U31PGS(WS)-E
11 1 1
11 1 1
44 4 4
22 2 2
22 2 2
4
4
33
33
11
11
22 2 2
22 2 2
22 2 2
44 4 4
22 2 2
11 1 1
11 1 1
22 2 2
22 2 2
11 1 1
11 1 1
4
4
322
315
318
320
316
317
305
304
314
313
321
310, 311
302
301
306, 307, 323, 324
312
308, 309
319
303
