TERMOROSSELLA PLUS EVO DSA - TERMONICOLETTA EVO DSA

24 7197201 - IT - EN - DE - FR

11. NORMAL OPERATION

After having positioned the registers correctly, insert the indicated hourly wood load avoiding overloads that cause anomalous stresses

and deformations. You should always use the product with the door closed in order to avoid damages due to overheating (forge

effect). The inobservance of this rule makes the warranty expire.

For safety reasons the door of the appliances with constructive system 1, must be opened only for the loading of the fuel or for removing

the ashes, while during the operation and the rest, the door of the hearth must remain closed.

The appliances with constructive system 2 must be connected to their own ue. The operating with open door is allowed under supervision.

IMPORTANT: For safety reasons the door of the hearth can be opened only for the loading of the fuel. The hearth door must

always remain closed during operation or rest.

With the controls positioned on the front of the appliance it is possible to adjust the heat emission of the hearth. They have to be opened

according to the caloric need. The best combustion (with minimum emissions) is reached when, by loading the wood, most part of the air

for combustion ows through the secondary air register.

Never overload the appliance (see the hourly wood load in the table here below). Too much fuel and too much air for the combustion may

cause overheating and then damage the stove. You should always use the appliance with the door closed in order to avoid damages due

to overheating (forge effect). The inobservance of this rule makes the warranty expire.

The adjustment of the registers necessary to reach the rated caloric yield with a depression at the stack of 17-20 Pa 1,7-2 mm of column

of water) is the following one: see chapter TECHNICAL DESCRIPTION. The appliance works as an intermittent operating appliance.

In the event that the water temperature exceeds the tripping temperature of the safety devices, immediately suspend the feeding

of wood, and make sure that the water temperature and the ame decrease, eliminating the causes of the overheating (if necessary

by closing the air register).

If the water system is connected in the thermo-replace, the hot water tap can be opened to speed up the cooling of the appliance.

Besides the adjustment of the air for the combustion, the intensity of the combustion and consequently the thermal performance of the

device is inuenced by the stack. A good draught of the stack requires a stricter adjustment of air for combustion, while a poor draught

requires a more precise adjustment of air for combustion.

To verify the good combustion, check whether the smoke coming out from the stack is transparent.

If it is white, it means that the device is not properly adjusted or the wood is too wet; if instead the smoke is gray or black, it signals that the

combustion is not complete (it is necessary a greater quantity of secondary air).

WARNING: When fuel is added onto the embers in the absence of a ame, a considerable amount of fumes may develop. Should this

happen, an explosive mixture of gas and air may form, and in extreme cases an explosion may occur. For safety reasons it is advisable

to perform a new lighting procedure with the use of small strips.

11.1. USE OF THE OVEN (If present)

Thanks to the air ow for the combustion, the temperature of the oven may become remarkably affected. A sufcient ue of the chimney

and of the channels, well cleaned for the ow of burning smokes around the oven are fundamental for a good cooking result. The oven pan

may be located on different plans. Thick cakes and big roasts must be introduced in the lowest level. Flat cakes and biscuits must reach

the medium level. The upper level may be used to heat or grill.

11.2. ELECTRICAL POWER SUPPLY FAILURE

In the event of an unexpected electrical power supply failure during normal system operation, it will be necessary to carry out these simple

manoeuvres to prevent the water in the boiler starting to boil as a consequence of the lack of pump operation.

1. Raise the moveable furnace grill (if present ) to the highest level in order to reduce the exchange surface exposed to the heat of the

ame.

2. Close the primary and secondary air registers in addition to turning the thermostat to 0 ( if present).

3. Open the oven door (if present) in order to favour the elimination of the internal heat.

4. Open the ue gas register ; in this way, it will deviate the residual heat still produced towards the chimney.

11.3. OPERATION IN TRANSITION PERIODS

During transition periods when the external temperatures are higher, if there is a sudden increase of temperature it can happen that the

combustion gases inside the ue cannot be completely sucked up.

The exhaust gases do not come out completely (intense smell of gas). In this case, shake the grating more frequently and increase the air

for the combustion. Then, load a reduced quantity of fuel in order to permit a rapid burning (growing up of the ames) and the stabilization

of the draught. Then, check that all openings for the cleaning and the connections to the stack are air-tigh.

In case of doubt, do not operate the product.

ATTENTION: never light for any reason if the installation is not completely full of water in order to avoid a serious damage of the whole

structure. The installation must always be full of water even when the thermo-replace is not used. A possible no use during winter

season must be faced by adding antifreeze substances.

11.4. SUMMER USE

The system must be completely lled with water. The absence of water in the system would lead to serious damage of the entire

structure. ATTENTION: For no reason must the re be ignited before the system has been completely lled with water; doing this would

lead to serious damage of the entire structure.
