TERMOSUPREMA COMPACT DSA / ITALY TERMO DSA

22 7095802

5. FIRE SAFETY

When installing the product, the following safety measures must be observed:

a) In order to ensure sufcient thermal insulation, respect the minimum safety distance from objects or furnishing components ammable

and sensitive to heat (furniture, wood sheathings, fabrics. etc.) and from materials with ammable structure (see Picture 5 at page 83 -

A). All the minimum safety distances are shown on the product data plate and lower values must not be used.

b) In front of the furnace door, in the radiation area there must be no ammable or heat-sensitive objects or material at a distance of less

than 100 cm. This distance can be reduced to 40 cm where a rear-ventilated, heat-resistant protection device is installed in front of the

The Product must always operate exclusively with the ash drawer inserted. The solid combustion residues (ash) must be collected in a

sealed, re resistant container. The Product must never be on in the presence of gaseous emissions or vapours (for example glue for

linoleum, petrol etc.). Never deposit ammable materials near the Product.

During combustion, thermal energy is released which leads to considerable heating of the surfaces, doors, handles, controls, glass parts,

the ue gas pipe and possibly the front part of the appliance. Avoid contact with these elements unless using suitable protective

clothing or accessories (heat resistant gloves, control devices).

Ensure children are aware of these dangers and keep them away from the furnace when it is on.

When using the wrong fuel or one which is too damp, due to deposits present in the ue, a ue re is possible.

5.1. IN A EMERGENCY

If there is a re in the ue connection :

When the ue stops burning, have it checked by a specialist to identify any cracks or permeable points.

6. TECHNICAL DESCRIPTION

La NORDICA thermocookers are ideal for holiday ats and weekend houses or as auxiliary heating all year round. Wooden logs are used

as fuel. The appliance works as an intermittent operating appliance.

The thermocooker is composed of galvanised steel sheet plates, enamelled cast iron and thermoradiant ceramic. The furnace is found

inside the boiler made with 4 mm thick steel and reinforced with welded nails. The water from the heating system, which absorbs the heat

produced in the furnace, circulates in the boiler. Inside the furnace, there is a height-adjustable at grill.

The furnace is equipped with a panoramic door with ceramic glass (resistant up to 700°C). This allows a fascinating view of the burning

ames. In addition, in this way there is no possibility of sparks or smoke escaping.

ACCESSORIES Poker Glove Chrome plated oven grille

The thermocooker is supplied with registers for primary and secondary air and a thermostat with which the combustion air is regulated.

A - PRIMARY Air Control (Picture 7 at page 84 ).

With the lower control, the passage of primary air in the lower part of the cooker is regulated through the ash drawer and the grill in

the direction of the fuel. The primary air is necessary for the combustion process. The ash drawer must be emptied regularly, so that

the ash cannot block the primary air intake for combustion. The primary air also keeps the ame alive. The primary air control must be

max. ¼ open during the combustion.

B - SECONDARY Air Control (Picture 7 at page 84 ).

This knob must be open (i.e. turned completely to the right), in particular for the combustion of wood (see Table). The secondary air,

passing between the double glass of the re door, heats up and triggers the dual combustion, keeping the glass clean at the same time

(control open).
