TERMOSUPREMA COMPACT DSA / ITALY TERMO DSA

7095802 29

13.11. CAST IRON COOKING PLATE AND RINGS

IMPORTANT: to avoid rust DO NOT forget pots or pans on the cold cooking plate. This would create rust rings, unpleasant to see and

difcult to remove.

The cast iron cooking plate and the cast iron rings needs to be periodically cleaned by using sandpaper (grain 150) without touching

the enamelled parts..

To carry out the cleaning operation remove the smoke outlet spigot and the smoke pipe. The smoke compartment can be cleaned from the

front side of the oven (see chap. CLEANING SMOKE COMPARTMENT COOKERS) or from the top. In this case remove the cast iron rings

To avoid the possible forming of rust it is recommended:

- To let the steam getting out of the oven to reduce the formation of any condensation by opening the door briey and carefully (1 or 2

times, or more often in case of cooking food very humid and with longer cooking times);

- Remove the food from the oven once cooked. Letting the food to chill in the oven at a temperature below 150 °C results in the forming

of condensation;

- After cooking, leave the oven door partially open to dry out any condensation;

- In case humidity formed inside the oven, we suggest you to treat with neutral vaseline the inside part of the cast iron door.

- Repeat the treatment with the neutral vaseline on the inside part of the cast iron door every 3-6 months, depending of the frequency

of the use of the oven;

- In case of presence of rust on the inside part of the cast iron door, remove the rust by using abrasive material and then treat the cast

the furnace and the pipes which compose the tube bundle located above the oven, as well as the downward passage of the smoke on the

right side of the oven. Later clean the smoke passage under the oven. Cleaning can be made with a brush and a vacuum cleaner.

IMPORTANT: please verify that the deectors are set as indicated in the Picture.

Pay ATTENTION that after cleaning all dismounted parts are reinstalled hermetically.

13.14. MAINTENANCE ON THE WATER SYSTEM

Excessive incrustation deposits on the inner walls of the hearth considerably reduce the efciency of heat exchange; therefore, remove

these deposits using a steel brush whenever necessary. Never use corrosive substances that can damage the thermo-replace and

the boiler.

With the system switched off, once a year carry out the following checks:

• Check the operation and efciency of the blowdown and safety valves. If they are defective, contact your authorised installer. IT IS
