Dell 3460 (3460-8964) [10/47] Installing the keyboard
![Dell 3460 (3460-8964) [10/47] Installing the keyboard](/views2/1349845/page10/bga.png)
Installing the keyboard
1. Connect the keyboard cables to the connectors on the system board.
2. Place the keyboard on the computer and press along all the sides until it clicks in place.
3. Install the battery.
4. Follow the procedure in After Working Inside Your computer.
Removing the hard drive assembly
1. Follow the procedure in Before Working Inside Your Computer.
2. Remove the:
a. battery
b. base cover
3. To remove the hard drive assembly:
a. Remove the screws that secure the hard drive assembly to the computer [1].
b. Disconnect the hard drive assembly cable from the connector on the system board [2].
c. Lift and remove the hard drive assembly from the computer [3].
10
