Dell 3460 (3460-8964) [21/47] Installing the system board

e. memory

f. keyboard

g. palmrest

h. display cable

i. system fan

3. To remove the system board:

a. Disconnect all the cables from the connectors on the system board.

b. Remove the screw that secures the system board to the computer [1].

c. Lift and remove the system board from the computer [2].

Installing the system board

1. Place the system board into the slot on the computer.

2. Connect all the cables to the connectors on the system board

3. Tighten the screw to secure the system board to the computer.

4. Install the:

a. system fan

b. display cable

c. palmrest

d. keyboard

e. memory

f. WLAN card

g. hard drive assembly

h. base cover

i. battery

5. Follow the procedure in After Working Inside Your computer.

Removing the heat sink

1. Follow the procedure in Before Working Inside Your Computer.

2. Remove the:

a. battery
