Dell 3460 (3460-8964) Инструкция по эксплуатации онлайн [30/47] 290965
![Dell 3460 (3460-8964) Инструкция по эксплуатации онлайн [30/47] 290965](/views2/1349845/page30/bg1e.png)
Table 2. General
Option Description
System
Information
This section lists the primary hardware features of your computer.
• System Information: Displays BIOS Version, Service Tag, Asset Tag, Ownership
Tag, Ownership Date, Manufacture Date, and the Express Service Code.
• Memory Information: Displays Memory Installed, Memory Available, Memory
Speed, Memory Channels Mode, Memory Technology, DIMM A Size, DIMM B Size,
• Processor Information: Displays Processor Type, Core Count, Processor ID,
Current Clock Speed, Minimum Clock Speed, Maximum Clock Speed, Processor
L2 Cache, Processor L3 Cache, HT Capable, and 64-Bit Technology.
• Device Information: Displays Primary Hard Drive, LOM MAC Address, Video
Controller, Video BIOS Version, Video Memory, Panel Type, Native Resolution,
Audio Controller, Wi-Fi Device, and Bluetooth Device.
Battery
Information
Displays the battery status and the type of AC adapter connected to the computer
Boot Sequence Boot Sequence Allows you to change the order in which
the computer attempts to find an
operating system. The options are:
• Windows Boot Manager
• UEFI: TOSHIBA MQ02ABF100
Boot List Option Allows you to change the boot list option.
• Legacy
• UEFI
Advanced Boot
Options
This option allows you the legacy option ROMs to load. By default, the Enable Legacy
Option ROMs is disabled.
Date/Time Allows you to change the date and time.
Table 3. System configuration
Option Description
Integrated NIC Allows you to configure the integrated network controller. The options
are:
• Disabled
• Enabled
• Enabled w/PXE: This option is enabled by default.
SATA Operation Allows you to configure the internal SATA hard-drive controller. The
options are:
• Disabled
• AHCI: This option is enabled by default.
Drives Allows you to configure the SATA drives on board. All drives are enabled
by default. The available drive is:
• SATA-0
SMART Reporting This field controls whether hard drive errors for integrated drives are
reported during system startup. This technology is part of the SMART
30
