Table 18. Audio
Feature Description
Type 4 channel high definition audio
Controller Realtek ALC3246
Stereo conversion 24-bit (analog-to-digital and digital-to-analog)
Interface Intel HDA bus
Speakers 2 W x 2 W
Volume controls Program menu and keyboard media-control keys
Table 19. Video
Feature Description
Video type Integrated on system board/discrete
Video controller
UMA
• Intel HD Celeron/Pentium
• Intel HD 5500 5th Generation, Intel Core i3, and Intel Core i5
Discrete GT920M
Data bus 64 bits
Table 20. Camera
Feature Description
Camera resolution 0.92 megapixels
Video resolution (maximum) 1280 x 720 (HD) at 30 fps (maximum)
Diagonal viewing angle 74°
NOTE: The RBG + IR camera is for Windows Hello application only and other applications cannot
use it.
Table 21. Communication
Feature Description
Network adapter 10/100/1000 Mbps Ethernet LAN on Motherboard (LOM)
Wireless Wi-Fi 802.11 b/g/n and 802.11a/b/g/n/ac
Table 22. Ports and Connectors
Feature Description
Audio one headphone/microphone combo port (headset)
Video
• one 15-pin VGA port
• one 19-pin HDMI port
43
