LifeGear 93800 [6/22] Parts list
![LifeGear 93800 [6/22] Parts list](/views2/1356003/page6/bg6.png)
5
PARTS LIST
No. Description Qty No. Description Qty
038 Computer ST-3604 1 063L Left Cover 1
039
Extension Sensor Wire
(L=1100 mm)
1 063R Right Cover 1
040
Cross Recessed Pan Head Bolt
M5x10
4 064 Foot Bar Bracket Ø38x3 2
041
Front Decorative Cover for Front
Post
1 065 Plastic Spacer Ø38xØ19x40 2
042
Rear Decorative Cover for Front
Post
1 066 Crank Disk Ø391x21 2
043
Cross Recessed Pan Head Bolt
M5x55
1 067 Crank 40x20x3 2
044 Curve Washer Ø5xØ19xδ1 1 068
Cross Recessed Pan Head
Tapping Screw ST4.2x15
16
045 Tension Control Knob 1 069 Spring Clip Ø17x1.0 2
046 Tension Cable L=1900 mm 1 070 Wave Washer Ø28xØ17x0.3 1
047 Front Post Ø60x1.5 1 071 Bearing 6003-2Z 2
048 Big Curve Washer Ø8xØ20x2 10 072 Main Frame 80x40x2 1
049 Plastic Bushing Ø32x69 2 073L Left Plastic Cover 1
050 Right Handrail Arm Cover-A 1 073R Right Plastic Cover 1
051 Right Handrail Arm Cover-B 1 074 Rubber Cover 2
052 Transport Wheel Ø45x19 2 075 Sensor with Wire (L=1600 mm) 1
053
Cross Recessed Pan Head Bolt
M6x35
2 076
Cross Recessed Pan Head
Tapping Screw ST2.9x12
2
054 Cap Nut M8 4 077 Hexagon Nut M6 2
055 Adjustable Leveler M10 2 078 Spring Washer Ø6 6
056 Carriage Bolt M8x65 4 079 Tension Bracket 31x30xδ1 2
057 Front Left Stabilizer End Cap 1 080 Eyebolt M6x36 2
058 Front Stabilizer 1 081 Nut M10x1x6 2
059 Front Right Stabilizer End Cap 1 082 Flywheel Ø260 1
060
Cross Recessed Pan Head
Tapping Screw ST4.2x25
11 083
Cross Recessed Pan Head Bolt
M6x10
1
061 Plastic Disc Cap 2 084 Bearing 6000-2Z 2
062 Nut M10x1.25x6 2 085 Washer Ø10xØ14x1 2
