ENGLISH

Before rst use

Thoroughly clean all parts before you use the appliance for the rst time (see

chapter ‘Cleaning’).

Note: Make sure all parts are completely dry before you start using the appliance.

Preparing for use

Assembling the juicing unit

1 Attach the pulp outlet to the juicing unit and turn it clockwise until the arrow

(

) points to the ‘locked’ indication. (Fig. 2)

2 Insert the juicing screw into the juicing unit (Fig. 3).

3 Assemble the two parts of the lter (Fig. 4).

4 Place the two-part lter over the juicing screw (Fig. 5).

Tip: Use the black two-part filter for clear juice. If you prefer cloudy juice with

more fibres in it, use the grey two-part filter.

5 Attach the spout to the juicing unit and turn it clockwise until the arrow (

)

points to the ‘locked’ indication. (Fig. 6)

Important: Do not attach or detach the spout when the juicing unit is mounted on

the motor unit. Always take o the juicing unit from the motor unit before

assembling or disassembling.

6 Place the berry tray on the feeding tube (Fig. 7).

Placing the juicing unit onto the motor unit

1 Place the assembled juicing unit onto the motor unit, with the pulp outlet

tting into the opening on the motor unit (Fig. 8).

2 Align the projections on the juicing unit with the recesses in the motor unit.

Slide the juicing unit onto the motor unit until it locks into place. (Fig. 9)

3 Press the juicing unit onto the motor unit (1) and then close the locking clamp

(2). (Fig. 10)

Note: If the locking clamp cannot be closed, check if the juicing unit is positioned

properly with the projections on the juicing unit into the recesses of the motor

unit.

4 Slide the pulp container into the motor unit (Fig. 11).

Using the appliance

The appliance only functions if the juicing unit and the pulp outlet are

assembled correctly and the locking clamp is locked properly.

1 Wash the fruit and/or vegetables. If necessary, cut them into pieces that t into

the feeding tube.

Note: Remove stones and thick peels of the fruits you would not eat, for example

from oranges, pomegranates etc.

2 Place a jug or a glass under the spout (Fig. 12).

3 Press the on/o button to switch on the appliance (Fig. 13).
