of number 5; lower speed is obtained when it is turned in
the direction of number 1.
Select the proper speed for the workpiece to be cut.
CAUTION:
• The speed adjusting dial can be turned only as far
as 5 and back to 1. Do not force it past 5 or 1, or the
speed adjusting function may no longer work.
Lighting up the lamps
Fig.3
CAUTION:
• Do not apply impact to the light, which may cause
damage or shorted service time to it.
To turn on the lamp, press the "I"(ON) side of the lamp
switch. Press the "O"(OFF) side to turn it off.
NOTE:
• Use a dry cloth to wipe the dirt off the lens of lamp.
Be careful not to scratch the lens of lamp, or it may
lower the illumination.
• Do not use thinner or gasoline to clean the lamp.
Such solvents may damage it.
• After operation, always turn off the light by
pressing .the "O (OFF)" side.
ASSEMBLY
CAUTION:
•
Always be sure that the tool is switched off and
unplugged before carrying out any work on the
tool.
Installing or removing the blade
CAUTION:
• Oil on the blade can cause the blade to slip or come
off unexpectedly. Wipe off all excess oil with a cloth
before installing the blade.
• Use caution when handling the blade so that you
are not cut by the sharp edge of the blade teeth.
Turn the blade tightening lever clockwise until it hits
against the protrusion on the frame.
Fig.4
Match the direction of the arrow on the blade to that of
the arrow on the wheels.
Fig.5
Insert the blade between the bearings of one blade guide
first and then into the other blade guide. The blade back
should contact the bearings in the lower portion of the
blade guides.
Position the blade around the wheels and insert the other
side of the blade within the upper holder and lower holder
until the blade back contacts the bottom of the upper
holder and lower holder.
Fig.6
Hold the blade in place and turn the blade-tightening
lever counterclockwise until it hits against the protrusion
on the frame. This places proper tension on the blade.
Make sure that the blade is correctly positioned within the
blade guard and around the wheels.
Start and stop the tool two or three times to make sure
that the blade runs properly on the wheels.
CAUTION:
• While making sure that the blade runs on the
wheels properly, keep your body away from the
blade area.
To remove the blade, follow the installation procedure in
reverse.
CAUTION:
• When turning the blade tightening lever clockwise
to release the tension on the blade, point the tool
downward because the blade may come off
unexpectedly.
Adjusting the protrusion of stopper plate
Fig.7
In the ordinary operation, protrude the stopper plate to
the A side fully.
When the stopper plate strikes against the obstacles like
a wall or the like at the finishing of a cut, loosen two
screws and slide it to the B side in the figure.
After sliding the stopper plate, secure it by tightening two
screws firmly.
OPERATION
It is important to keep at least two teeth in the cut. Select
the proper cutting position for your workpiece by referring
to the figure.
Fig.8
Hold the tool by both hands as shown in the figure with
the stopper plate contacting the workpiece and the blade
clear of the workpiece.
Fig.9
Turn the tool on and wait until the blade attains full speed.
Gently lower the blade into the cut. The weight of the tool
or slightly pressing the tool will supply adequate pressure
for the cutting. Do not force the tool.
As you reach the end of a cut, release pressure and,
without actually raising the tool, lift it slightly so that it will
not fall against the workpiece.
CAUTION:
• Applying excessive pressure to the tool or twisting
of the blade may cause bevel cutting or damage to
the blade.
• When not using the tool for a long period of time,
remove the blade from the tool.
