4
English
○ Delay the feed speed when cutting the material into
small circular arcs. An unreasonably fast feed may break
the blade.
Plunge cutting (Fig. 10 and 11)
○ Avoid plunge cutting for metallic materials. This can
easily damage the blade.
○ Never pull the switch trigger while the tip of the saw
blade tip is pressed against the material. If you do so, the
blade can easily be damaged when it collides with the
material.
○ Make absolutely sure that you cut slowly while holding
the body fi rmly. If you apply any unreasonable force to
the saw blade during the cutting operation, the blade can
easily be damaged.
12. Cut off guide for cutting pipe (optional accessory)
Please refer to the cut off guide user’s manual for details
on how to use it correctly.
SYMBOLS
WARNING
The following show symbols used for the machine. Be
sure that you understand their meaning before use.
CR13VBY: Reciprocating Saw
Read all safety warnings and all instructions.
Only for EU countries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive 2002/96/
EC on waste electrical and electronic equipment
and its implementation in accordance with
national law, electric tools that have reached
the end of their life must be collected separately
and returned to an environmentally compatible
recycling facility.
Switching ON
Switching OFF
Straight cutting
Swing cutting
Stroke
Disconnect mains plug from electrical outlet
Class II tool
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package
contains the accessories listed in the below.
○ Blade (No. 341) .............................................................1
○ Case .............................................................................1
Standard accessories are subject to change without notice.
APPLICATIONS
○ Cutting pipe and angle steel.
○ Cutting various lumbers.
○ Cutting mild steel plates, aluminum plates, and copper
plates.
○ Cutting synthetic resins, such as phenol resin and vinyl
chloride.
For details refer to the section entitled “SELECTION OF
BLADES”.
SPECIFICATIONS
Voltage (by areas) *
(110 V, 115 V, 120 V, 127 V,
220 V, 230 V, 240 V)
Power Input * 1150 W
Capacity
Mild Steel Pipe O.D. 130 mm
Vinyl Chloride
Pipe
O.D. 130 mm
Wood Depth 300 mm
Mild Steel Plate Thickness 19 mm
No-Load Speed 0 – 3000 min
–1
Stroke 32 mm
Weight (without cord) 4,4 kg
* Be sure to check the nameplate on product as it is subject
to change by areas.
NOTE
Due to HITACHI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
MOUNTING AND OPERATION
Action Figure Page
Mounting the blade 1 146
Taking the broken blade out 2 146
Maintenance and inspection of
saw blade mount
3 146
Blade hole 4 146
Adjusting the base 5 147
Switch Operation 6 147
Adjusting the swing cutting
operation
7 147
Selection of saw blade length 8 148
Fastening work piece fi rmly 9 148
Plunge cutting 10 148
Plunge cutting with the saw blade
installed in reverse
11 149
Replacing carbon brushes 12 149
Selecting accessories ― 150
Refer to Table 1, 2, 3 and 4 for use of the blades.
Adjusting the base (Fig. 5)
This unit employs a mechanism that can adjust the base
mounting position in three stages without the use of a
wrench or other tools.
0000Book_CR13VBY.indb 40000Book_CR13VBY.indb 4 2014/12/25 14:41:482014/12/25 14:41:48
