English
7
5. Installing a socket (Impact wrench)
Select the socket to be used.
䢇 Pin, O-ring type
(1) Align the hole in the socket with the hole in the anvil
and insert the anvil into the socket.
(2) Insert the pin into the socket.
(3) Attach the ring to the groove on the socket.
䢇 Plunger type (Fig. 3)
Align the plunger located in the square part of the
anvil B with the hole in the hex. socket 0. Then push
the plunger, and mount the hex. socket 0 on the anvil
B. Check that the plunger is fully engaged in the hole.
When rem oving the socket 0, reverse the sequence.
䢇 Retaining ring type
(1) Align the square portions of the socket and the anvil
with each other.
(2) Make sure to firm ly install the socket by pushing it all
the way into the anvil.
(3) When rem oving the socket, pull it out of the anvil.
CAUTION
䡬 Please use the designated attachments w hich are
listed in the operations manual and Hitachi’s catalog.
Accidents or injuries could result from not doing so.
䡬 Make sure to firm ly install the socket in the anvil. If
the socket is not firmly installed it might come out
and cause injuries.
HOW TO USE
CAUTION
䡬 When using the light equipped hook, pay sufficient
attention so that the main equipment does not fall. If
the tool falls, there is a risk of accident.
䡬 Do not attach the tip tool except phillips bit to the tool
main unit when carrying the tool main unit with the
light equipped hook suspended from a waist belt.
Injury may result if you carry the equipment
suspended from the waist belt with sharp tipped
components such as drill bit attached.
1. Using the light equipped hook
The light equipped hook can be installed on the right
or left side and the angle can be adjusted in 5 steps
between 0° and 80°.
(1) Operating the hook
(a) Pull out the hook E toward you in the direction of
arrow (A) and turn in the direction of arrow (B)
(Fig. 5).
(b) The angle can be adjusted in 5 steps (0°, 20°, 40°,
60°, 80°).
Adjust the angle of the hook to the desired position
for use.
(2) Switching the hook position
CAUTION
Incomplete installation of the hook may result in
bodily injury when used.
(a) Securely hold the main unit and remove the screw
using a slotted head screwdriver or a coin (Fig. 6).
(b) Remove the hook E and spring F (Fig. 7).
(c) Install the hook E and spring F on the other side
and securely fasten with screw (Fig. 8).
NOTE
Pay attention to the spring F orientation. Install the
spring F with larger diameter G away from you
(Fig. 8).
(3) Using as an auxiliary light
(a) Press the sw itch H to turn off the light.
If forgotten, the light will turn off automatically
after 15 minutes.
(b) The direction of the light can be adjusted within
the range of hook positions 1 – 5 (Fig. 9).
䡬 Lighting time
AAAA m anganese batteries: approx. 15 hrs.
AAAA alkali batteries: approx. 30 hrs.
CAUTION
Do not look directly into the light.
Such actions could result in eye injury.
(4) Replacing the batteries
(a) Loosen the hook screw J with a phillips-head
screwdriver (No. 1) I (Fig. 10).
Remove the hook cover L by pushing in the
direction of the arrow (Fig. 11).
(b) Remove the old batteries and insert the new
batteries. Align with the hook indications and
position the plus (+) and minus (–) term inals
correctly (Fig. 12).
(c) Align the indentation in the hook E main body
with the protuberance of the hook cover L, press
the hook cover L in the direction opposite to that
of the arrow K shown in Fig. 11 and then tighten
the screw.
Use commercially available AAAA batteries
(1.5 V) O.
NOTE
Do not tighten the screw excessively. Such action
could strip the screw threads.
CAUTION
䡬 Failure to observe the following can result in battery
leakage, rust or malfunction.
Position the plus (+) and minus (–) terminals correctly.
Replace both batteries at the same time. Do not mix
old and new batteries.
Remove exhausted batteries from the hook
immediately.
䡬 Do not discard batteries together with normal trash
and do not throw batteries into fire.
䡬 Store batteries out of the reach of children.
䡬 Use batteries correctly in accordance with the battery
specifications and indications.
2. Check the rotational direction
The bit rotates clockwise (viewed from the rear side)
by pushing the R-side of the push button C.
The L-side of the push button is pushed to turn the bit
counterclockwise (See Fig. 4) (The
L
and
R
marks
are provided on the body).
CAUTION
The push button cannot be switched while the impact
driver is turning. To switch the push button, stop the
impact driver, then set the push button.
3. Switch operation
䡬 When the trigger switch is depressed, the tool rotates.
When the trigger is released, the tool stops.
䡬 The rotational speed can be controlled by varying the
amount that the trigger switch is pulled. Speed is low
when the trigger switch is pulled slightly and increases
as the trigger switch is pulled more.
4. Tightening and loosening screws (Impact driver)
Install the bit that matches the screw, line up the bit in
the grooves of the head of the screw, then tighten it.
Push the im pact driver just enough to keep the bit
fitting the head of the screw.
